ACS 600 MultiDrive – Technical Data
A-30 ACS 600 MultiDrive
Diode Supply Sections The connection holes for cable lugs and bus duct are presented below.
Thyristor Supply
Section: Terminal Block
Connection
The maximum cable size accepted by the terminal block of frame type
B1 is given below.
Type Holes for
cable lugs per
phase
Number of
cable entries
at bottom
(diameter
60 mm)
Bottom plate
opening
dimensions
(mm)
Number of
cable entries
at top
(diameter
60 mm)
Holes for bus duct
connection
U
N
= 400V (380V...415V)
ACA 631-0140-3 2x14 3 310x240 3 -
ACA 631-0200-3 2x14 3 310x240 3 -
ACA 631-0300-3 4x14 6 502x280 6 -
ACA 631-0420-3 4x14 6 502x280 6 -
ACA 631-0680-3 4x(13x18) 12 502x280 12 4x(13x24)
ACA 631-1120-3 8x(13x18) 12 502x280 12 4x(13x24)
ACA 631-1700-3 12x(13x18) 18 502x280 18 4x(13x24)
ACA 631-2100-3 12x(13x18) 18 502x280 18 4x(13x24)
U
N
= 500V (380V...500V)
ACA 631-0175-5 2x14 3 310x240 3 -
ACA 631-0250-5 2x14 3 310x240 3 -
ACA 631-0375-5 4x14 6 502x280 6 -
ACA 631-0525-5 4x14 6 502x280 6 -
ACA 631-0850-5 4x(13x18) 12 502x280 12 4x(13x24)
ACA 631-1400-5 8x(13x18) 12 502x280 12 4x(13x24)
ACA 631-2120-5 12x(13x18) 18 502x280 18 4x(13x24)
ACA 631-2600-5 12x(13x18) 18 502x280 18 4x(13x24)
U
N
= 690V (525V...690V)
ACA 631-0090-6 2x14 3 310x240 3 -
ACA 631-0175-6 2x14 3 310x240 3 -
ACA 631-0250-6 2x14 3 310x240 3 -
ACA 631-0375-6 4x14 6 502x280 6 -
ACA 631-0525-6 4x14 6 502x280 6 -
ACA 631-0850-6 4x(13x18) 12 502x280 12 4x(13x24)
ACA 631-1400-6 8x(13x18) 12 502x280 12 4x(13x24)
ACA 631-2600-6 12x(13x18) 18 502x280 18 4x(13x24)
ACA 631-3600-6 12x(13x18) 18 502x280 18 4x(13x24)
Types:
ACA 632-0015-3
ACA 632-0030-3
ACA 632-0040-3
ACA 632-0070-3
ACA 632-0020-5
ACA 632-0035-5
ACA 632-0050-5
ACA 632-0090-5
Frame
Size
B1
Cable Size Tightening
Torgue
Cable entries
at bottom
(diameter
60 mm)
Bottom plate
opening
dimensions
Cable entries at
top (diameter
60 mm)
mm
2
AWG Nm pcs mm pcs
70 2/0 8 3 310x240 3
