ACS 600 MultiDrive – Technical Data
A-4 ACS 600 MultiDrive
Ratings 380...500 V The table below shows the nominal ratings for the 500 V range supply
sections.
Type Marking Nominal Ratings Duty Cycle
(10 s / 60 s)
Duty Cycle
(1 min / 5 min)
Frame Air Flow
m
3
/h
P
loss
kW
Noise
Level
dBA
S
N
kVA
I
1N
A
I
DC
A
P
N
kW
P
G
kW
I
DCbase
A
I
DCmax
A
I
DCbase
A
I
DCmax
A
Diode supply sections (380...500 V Range,U
N
= 500 V)
ACA 631-0175-51-xx 175 202 247 163 – 148 317 148 289 B2 370 1.5 56
ACA 631-0250-51-xx 250 289 354 233 – 212 455 212 414 B2 370 2.3 56
ACA 631-0375-51-xx 375 433 530 349 – 318 795 318 700 B3 770 2.8 64
ACA 631-0525-51-xx 525 606 742 489 – 445 1113 445 979 B3 770 3.6 64
ACA 631-0850-51-xx 850 981 1202 792 – 721 1947 721 1406 B4 1500 6.3 70
ACA 631-1400-51-xx 1400 1617 1980 1304 – 1188 3208 1188 2317 B4 1500 10.2 70
ACA 631-2120-51-xx 2120 2449 3000 1976 – 1800 4860 1800 3798 B5 2800 16.5 74
ACA 631-2600-51-xx 2475 2858 3500 2305 – 2100 5670 2100 4431 B5 2800 20.8 74
Thyristor supply sections (380...500 V Range,U
N
= 500 V)
ACA 632-0020-51-xx 16 18 22 15 13 13 28 13 26 B1 150 1.1 55
ACA 632-0035-51-xx 32 37 45 30 27 27 58 27 53 B1 150 1.1 55
ACA 632-0050-51-xx 47 55 67 44 40 40 86 40 78 B1 150 1.1 55
ACA 632-0090-51-xx 88 102 125 82 74 75 161 75 146 B1 150 1.1 55
ACA 632-0175-51-xx 175 202 247 163 147 148 317 148 289 B2 370 1.5 56
ACA 632-0250-51-xx 250 289 354 233 210 212 455 212 414 B2 370 2.3 56
ACA 632-0375-51-xx 375 433 530 349 314 318 795 318 700 B3 770 2.8 64
ACA 632-0525-51-xx 525 606 742 489 440 445 1113 445 979 B3 770 3.6 64
ACA 632-0850-51-xx 850 981 1202 792 713 721 1947 721 1406 B4 2500 6.3 72
ACA 632-1400-51-xx 1400 1617 1980 1304 1174 1188 3208 1188 2317 B4 2500 10.2 72
ACA 632-2120-51-xx 2120 2449 3000 1976 1778 1800 4860 1800 3798 B5 4500 16.5 75
ACA 632-2600-51-xx 2475 2858 3500 2305 2074 2100 5670 2100 4431 B5 4500 20.8 75
Asymmetrical thyristor supply sections (380...500 V Range,U
N
= 500 V)
ACA 632-2120/0850-51-xx 2120 2449 3000 1976 713 1800 4860 1800 3798 B5 4500 16.5 75
ACA 632-2120/1400-51-xx 2120 2449 3000 1976 1174 1800 4860 1800 3798 B5 4500 16.5 75
ACA 632-2600/0850-51-xx 2475 2858 3500 2305 713 2100 5670 2100 4431 B5 4500 20.8 75
ACA 632-2600/1400-51-xx 2475 2858 3500 2305 1174 2100 5670 2100 4431 B5 4500 20.8 75
12 pulse diode supply sections (380...500 V Range,U
N
= 500 V)
ACA 633-0350-51-xx 350 404 494 326 – 296 634 296 578 B2 2x370 2x1.5 56
ACA 633-0500-51-xx 500 578 708 466 – 425 909 425 828 B2 2x370 2x2.3 56
ACA 633-0750-51-xx 750 866 1060 698 – 636 1590 636 1399 B3 2x770 2x2.8 64
ACA 633-1050-51-xx 1050 1212 1484 978 – 890 2226 890 1959 B3 2x770 2x3.6 64
ACA 633-1700-51-xx 1700 1962 2404 1584 – 1442 3894 1442 2813 B4 2x1500 2x6.3 72
ACA 633-2800-51-xx 2800 3234 3960 2608 – 2376 6415 2376 4633 B4 2x1500 2x10.2 72
ACA 633-4240-51-xx 4240 4898 6000 3952 – 3600 9720 3600 7596 B5 2x2800 2x16.5 75
6 pulse thyristor supply sections with autotransformer (380...500 V Range,U
N
= 500 V)
ACA 634-0250-51-xx 250 289 354 233 190 212 455 212 414 B2 370 2.3 56
ACA 634-0375-51-xx 375 433 530 349 380 318 795 318 700 B3 770 2.8 64
ACA 634-0850-51-xx 850 981 1202 792 645 721 1947 721 1406 B4 2500 6.3 72
ACA 634-1400-51-xx 1400 1617 1980 1304 1063 1188 3208 1188 2317 B4 2500 10.2 72
ACA 634-2120-51-xx 2120 2449 3000 1976 1063 1800 4860 1800 3798 B5 4500 16.5 75
ACA 634-2600-51-xx 2475 2858 3500 2305 1874 2100 5670 2100 4431 B5 4500 20.8 75
12 pulse thyristor supply sections (380...500 V Range,U
N
= 500 V)
ACA 636-1000-51-xx 997 1151 1410 929 836 846 2115 846 1861 B3 2x770 2x3.6 66
ACA 636-1615-51-xx 1614 1864 2283 1504 1353 1370 3700 1370 2672 B4 2x2500 2x6.3 74
ACA 636-2660-51-xx 2661 3072 3764 2479 2231 2257 6094 2257 4402 B4 2x2500 2x10.2 74
ACA 636-4030-51-xx 4030 4653 5700 3754 3378 3420 9234 3420 7216 B5 2x4500 2x16.5 77
ACA 636-4700-51-xx 4703 5430 6652 4381 3943 3990 10773 3990 8419 B5 2x4500 2x20.8 77
12 pulse thyristor supply sections with autotransformer (380...500 V Range,U
N
= 500 V)
ACA 638-1000-51-xx 997 1151 1410 929 722 846 2115 846 1861 B3 2x770 2x3.6 66
ACA 638-1615-51-xx 1614 1864 2283 1504 1170 1370 3700 1370 2672 B4 2x2500 2x6.3 74
ACA 638-2660-51-xx 2661 3072 3764 2479 1927 2257 6094 2257 4402 B4 2x2500 2x10.2 74
ACA 638-4030-51-xx 4030 4653 5700 3754 3580 3420 9234 3420 7216 B5 2x4500 2x16.5 77
ACA 638-4700-51-xx 4703 5430 6652 4381 3580 3990 10773 3990 8419 B5 2x4500 2x20.8 77
12/6 pulse thyristor supply sections with autotransformer (380...500 V Range,U
N
= 500 V)
ACA 639-1000-51-xx 997 1151 1410 929 361 846 2115 846 1861 B3 2x770 2x3.6 66
ACA 639-1615-51-xx 1614 1864 2283 1504 585 1370 3700 1370 2672 B4 4000 2x6.3 74
ACA 639-2660-51-xx 2661 3072 3764 2479 963 2257 6094 2257 4402 B4 4000 2x10.2 74
ACA 639-4030-51-xx 4030 4653 5700 3754 1790 3420 9234 3420 7216 B5 7300 2x16.5 77
ACA 639-4700-51-xx 4703 5430 6652 4381 1790 3990 10773 3990 8419 B5 7300 2x20.8 77
