ACS 600 MultiDrive – Technical Data
ACS 600 MultiDrive A-5
Ratings 525...690 V The table below shows the nominal ratings for the 690 V range supply
sections.
Type Marking Nominal Ratings Duty Cycle
(10 s / 60 s)
Duty Cycle
(1 min / 5 min)
Frame Air Flow
m
3
/h
P
loss
kW
Noise
Level
dBA
S
N
kVA
I
1N
A
I
DC
A
P
N
kW
P
G
kW
I
DCbase
A
I
DCmax
A
I
DCbase
A
I
DCmax
A
Diode supply sections (525...690 V Range,U
N
= 690 V)
ACA 631-0090-61-xx 90 75 92 83 – 55 118 55 108 B2 370 0.6 56
ACA 631-0175-61-xx 175 146 179 161 – 107 230 107 209 B2 370 1.5 56
ACA 631-0250-61-xx 250 209 256 231 – 154 329 154 300 B2 370 2.3 56
ACA 631-0375-61-xx 375 314 384 346 – 230 576 230 507 B3 770 2.8 64
ACA 631-0525-61-xx 525 439 538 484 – 323 807 323 710 B3 770 3.6 64
ACA 631-0850-61-xx 850 711 871 784 – 523 1411 523 1019 B4 1500 6.3 70
ACA 631-1400-61-xx 1400 1171 1435 1292 – 861 2325 861 1679 B4 1500 10.2 70
ACA 631-2600-61-xx 2600 2176 2664 2400 – 1598 4316 1598 3373 B5 2800 16.5 74
ACA 631-3600-61-xx 3415 2858 3500 3152 – 2100 5670 2100 4431 B5 2800 20.8 74
Thyristor supply sections (525...690 V Range,U
N
= 690 V)
ACA 632-0090-61-xx 90 75 92 83 74 55 118 55 108 B2 370 0.6 56
ACA 632-0175-61-xx 175 146 179 161 145 107 230 107 209 B2 370 1.5 56
ACA 632-0250-61-xx 250 209 256 231 207 154 329 154 300 B2 370 2.3 56
ACA 632-0375-61-xx 375 314 384 346 312 230 576 230 507 B3 770 2.8 64
ACA 632-0525-61-xx 525 439 538 484 436 323 807 323 710 B3 770 3.6 64
ACA 632-0850-61-xx 850 711 871 784 706 523 1411 523 1019 B4 2500 6.3 72
ACA 632-1400-61-xx 1400 1171 1435 1292 1163 861 2325 861 1679 B4 2500 10.2 72
ACA 632-2600-61-xx 2600 2176 2664 2399 2159 1598 4316 1598 3373 B5 4500 16.5 75
ACA 632-3600-61-xx 3415 2858 3500 3152 2837 2100 5670 2100 4431 B5 4500 20.8 75
Asymmetrical thyristor supply sections (525...690 V Range,U
N
= 690 V)
ACA 632-2600/0850-61-xx 2600 2176 2664 2399 706 1598 4316 1598 3373 B5 4500 16.5 75
ACA 632-2600/1400-61-xx 2600 2176 2664 2399 1163 1598 4316 1598 3373 B5 4500 16.5 75
ACA 632-3600/0850-61-xx 3415 2858 3500 3152 706 2100 5670 2100 4431 B5 4500 20.8 75
ACA 632-3600/1400-61-xx 3415 2858 3500 3152 1163 2100 5670 2100 4431 B5 4500 20.8 75
ACA 632-3600/2600-61-xx 3415 2858 3500 3152 2159 2100 5670 2100 4431 B5 4500 20.8 75
12 pulse diode supply sections (525...690 V Range,U
N
= 690 V)
ACA 633-0180-61-xx 180 150 184 165 – 110 236 110 215 B2 2x370 2x0.6 56
ACA 633-0350-61-xx 350 292 358 322 – 215 460 215 419 B2 2x370 2x1.5 56
ACA 633-0500-61-xx 500 418 512 461 – 307 657 307 599 B2 2x370 2x2.3 56
ACA 633-0750-61-xx 750 628 768 693 – 461 1152 461 1014 B3 2x770 2x2.8 64
ACA 633-1050-61-xx 1050 878 1076 968 – 646 1614 646 1420 B3 2x770 2x3.6 64
ACA 633-1700-61-xx 1700 1422 1742 1569 – 1045 2822 1045 2038 B4 2x1500 2x6.3 72
ACA 633-2800-61-xx 2800 2342 2870 2583 – 1722 4649 1722 3358 B4 2x1500 2x10.2 72
ACA 633-5200-61-xx 5200 4352 5328 4798 – 3197 8631 3197 6745 B5 2x2800 2x16.5 75
6 pulse thyristor supply sections with autotransformer (525...690 V Range,U
N
= 690 V)
ACA 634-1400-61-xx 1400 1171 1435 1292 1063 861 2325 861 1679 B4 2500 10.2 72
ACA 634-2600-61-xx 2600 2176 2664 2399 1874 1598 4316 1598 3373 B5 4500 16.5 75
ACA 634-3600-61-xx 3415 2858 3500 3152 1874 2100 5670 2100 4431 B5 4500 20.8 75
12 pulse thyristor supply sections (525...690 V Range,U
N
= 690 V)
ACA 636-1000-61-xx 997 834 1022 920 828 613 1533 613 1349 B3 2x770 2x3.6 66
ACA 636-1615-61-xx 1614 1351 1655 1490 1341 993 2681 993 1936 B4 2x2500 2x6.3 74
ACA 636-2660-61-xx 2659 2225 2726 2455 2209 1636 4417 1636 3190 B4 2x2500 2x10.2 74
ACA 636-4950-61-xx 4941 4134 5065 4561 4105 3037 8200 3037 6408 B5 2x4500 2x16.5 77
ACA 636-6500-61-xx 6490 5430 6652 5991 5392 3990 10773 3990 8419 B5 2x4500 2x20.8 77
12 pulse thyristor supply sections with autotransformer (525...690 V Range,U
N
= 690 V)
ACA 638-1615-61-xx 1614 1351 1655 1490 1344 993 2681 993 1936 B4 2x2500 2x6.3 74
ACA 638-2660-61-xx 2659 2225 2726 2455 2214 1636 4417 1636 3190 B4 2x2500 2x10.2 74
ACA 638-4950-61-xx 4941 4134 5065 4561 3905 3037 8200 3037 6408 B5 2x4500 2x16.5 77
ACA 638-6500-61-xx 6490 5430 6652 5991 3905 3990 10773 3990 8419 B5 2x4500 2x20.8 77
12/6 pulse thyristor supply sections with autotransformer (525...690 V Range,U
N
= 690 V)
ACA 639-1615-61-xx 1614 1351 1655 1490 672 993 2681 993 1936 B4 4000 2x6.3 74
ACA 639-2660-61-xx 2659 2225 2726 2455 1107 1636 4417 1636 3190 B4 4000 2x10.2 74
ACA 639-4950-61-xx 4941 4134 5065 4561 1952 3037 8200 3037 6408 B5 7300 2x16.5 77
ACA 639-6500-61-xx 6490 5430 6652 5991 1952 3990 10773 3990 8419 B5 7300 2x20.8 77
PDM code 00001749-C
