ACS 600 MultiDrive – Technical Data
ACS 600 MultiDrive A-15
Ratings 690 V
The table below shows the nominal ratings for the 690 V range drive
sections.
Type Mar k i ng
Nominal Ratings
Duty Cycle
(10 s / 60 s)
Duty Cycle
(1 min / 5 min)
Frame
type
P
loss
kW
Air flow
m
3
/h
Noise
level
dBA
Width
mm
Weight
kg
Notes
S
N
kVA
P
N
kW
I
2N
A
I
2base
A
I
2max
A
I
2base
A
I
2max
A
Drive sections (525...690 V Range, U
N
= 690 V)
ACA 610-09/00/00-6 9 5.5 7.6 6.2 12 6.2 9 R3i 0,14 60 48
400 170 1
ACA 610-09/09/00-6 2xR3i 0,28 120 50
400 or 600 210 1, 6
ACA 610-09/09/09-6 3xR3i 0,42 180 51
400 or 600 220 1, 6
ACA 610-11/00/00-6 11 8 10 8.7 17 8.7 13 R3i 0,17 60 48
400 170 1
ACA 610-11/11/00-6 2xR3i 0,34 120 50
400 or 600 210 1, 6
ACA 610-11/11/11-6 3xR3i 0,51 180 51
400 or 600 220 1, 6
ACA 610-16/00/00-6 16 11 14 10 20 10 15 R3i 0,24 60 48
400 170 1
ACA 610-16/16/00-6 2xR3i 0,48 120 50
400 or 600 210 1, 6
ACA 610-16/16/16-6 3xR3i 0,72 180 51
400 or 600 220 1, 6
ACA 610-20/00/00-6 20 15 20 15 30 15 23 R3i 0,30 60 48
400 170 1
ACA 610-20/20/00-6 2xR3i 0,60 120 50
400 or 600 210 1, 6
ACA 610-20/20/20-6 3xR3i 0,90 180 51
400 or 600 220 1, 6
ACA 610-025/000-6 25 19 25 20 40 20 30 R4i 0,38 70 54
400 240 1, 6
ACA 610-025/025-6 2xR4i 0,76 140 54
400 or 600 190 1
ACA 610-030/000-6 30 22 28 25 50 25 38 R4i 0,45 100 54
400 240 1, 6
ACA 610-030/030-6 2xR4i 0,90 200 54
400 or 600 190 1
ACA 610-040/000-6 40 30 36 28 56 28 42 R5i 0,60 260 54
400 240 1, 6
ACA 610-040/040-6 2xR5i 1,20 520 54
400 or 600 190 1
ACA 610-050/000-6 50 37 44 36 72 36 54 R5i 0,75 260 54
400 240 1, 6
ACA 610-050/050-6 2xR5i 1,50 520 54
400 or 600 190 1
ACA 610-060/000-6 60 45 52 44 88 44 66 R6i 0,90 480 64
400 200 1
ACA 610-060/060-6 2xR6i 1,80 960 68
600 250 1
ACA 610-070/000-6 70 55 65 52 104 52 78 R6i 1,05 480 64
400 200 1
ACA 610-070/070-6 2xR6i 2,10 960 68
600 250 1
ACA 610-100/000-6, 100 75 88 65 130 65 98 R7i 1,50 480 64
400 200 1
ACA 610-100/100-6 2xR7i 3,00 960 68
600 250 1
ACA 610-120/000-6 120 90 105 88 176 88 132 R7i 1,80 480 64
400 200 1
ACA 610-120/120-6 2xR7i 3,60 960 68
600 250 1
ACA 610-0185-6 180 132 149 106 212 112 168 R8i 2,70 1550 61
600 250 2
ACA 610-0205-6 210 160 176 127 254 132 198 R8i 3,15 1550 61
600 250 2
ACA 610-0255-6 250 200 210 150 300 158 236 R8i 3,75 1550 61
600 250 2
ACA 610-315-6 310 250 264 179 358 198 297 R8i 4,65 1550 61
600 250 2
ACA 610-375-6 370 315 310 225 450 233 349 R9i 5,55 1550 61
600 270 2
ACA 610-0485-6 490 400 410 265 530 308 461 R9i 7,35 1550 61
600 270 2
ACA 610-600-6 600 500 502 340 680 377 565 R10i 9,00 3100 66
1000 450 2
ACA 610-0750-6 750 630 630 428 856 473 709 R11i 11,25 3100 66
1000 480 2
ACA 610-900-6 900 - 755 504 1008 566 849 R11i 13,50 3100 66
1000 480 2
ACA 610-1045-6 1040 - 874 641 1282 656 983 R12i 15,60 4650 69
1500 950 3
ACA 610-1385-6 1380 - 1156 755 1510 867 1301 R12i 20,70 4650 69
1500 950 3
ACA 610-1710-6 1710 - 1435 1007 2014 1076 1614 2xR11i 25,65 6200 69
2x1000 1200 3, 5
ACA 610-2125-6 2120 - 1777 1283 2566 1333 1999 2xR12i 31,80 9300 71
2x1500 1900 4
ACA 610-2545-6 2540 - 2129 1511 3022 1597 2395 2xR12i 38,10 9300 71
2x1500 1900 4
ACA 610-2800-6 2800 - 2344 1710 3420 1758 2637 4xR11i 42,00 12400 71
4x1000 2400 4
ACA 610-3350-6 3350 - 2809 2014 4028 2107 3160 4xR11i 50,25 12400 71
4x1000 2400 4
ACA 610-3880-6 3880 - 3251 2564 5128 2438 3657 4xR12i 58,20 18600 72
4x1500 3800 4
ACA 610-5140-6 5140 - 4300 3020 6040 3225 4838 4xR12i 77,10 18600 72
4x1500 3800 4
