ACS 600 MultiDrive – Technical Data
ACS 600 MultiDrive A-31
Thyristor Supply
Section: Busbar / Bus
Duct Connection
The connection holes for cable lugs and bus duct are presented below.
Type Holes for
cable lugs per
phase
Number of
cable entries
at bottom
(diameter
60 mm)
Bottom plate
opening
dimensions
(mm)
Number of
cable entries
at top
(diameter
60 mm)
Holes for bus duct
connection
U
N
= 400V (380V...415V)
ACA 632-0140-3 2x14 3 310x240 3 -
ACA 632-0200-3 2x14 3 310x240 3 -
ACA 632-0300-3 4x14 6 502x280 6 -
ACA 632-0420-3 4x14 6 502x280 6 -
ACA 632-0680-3 4x(13x18) 12 502x280 12 4x(13x24)
ACA 632-1120-3 8x(13x18) 12 502x280 12 4x(13x24)
ACA 632-1700-3 12x(13x18) 18 502x280 18 4x(13x24)
ACA 632-2100-3 12x(13x18) 18 502x280 18 4x(13x24)
U
N
= 500V (380V...500V)
ACA 632-0175-5 2x14 3 310x240 3 -
ACA 632-0250-5 2x14 3 310x240 3 -
ACA 632-0375-5 4x14 6 502x280 6 -
ACA 632-0525-5 4x14 6 502x280 6 -
ACA 632-0850-5 4x(13x18) 12 502x280 12 4x(13x24)
ACA 632-1400-5 8x(13x18) 12 502x280 12 4x(13x24)
ACA 632-2120-5 12x(13x18) 18 502x280 18 4x(13x24)
ACA 632-2600-5 12x(13x18) 18 502x280 18 4x(13x24)
U
N
= 690V (525V...690V)
ACA 632-0090-6 2x14 3 310x240 3 -
ACA 632-0175-6 2x14 3 310x240 3 -
ACA 632-0250-6 2x14 3 310x240 3 -
ACA 632-0375-6 4x14 6 502x280 6 -
ACA 632-0525-6 4x14 6 502x280 6 -
ACA 632-0850-6 4x(13x18) 12 502x280 12 4x(13x24)
ACA 632-1400-6 8x(13x18) 12 502x280 12 4x(13x24)
ACA 632-2600-6 12x(13x18) 18 502x280 18 4x(13x24)
ACA 632-3600-6 12x(13x18) 18 502x280 18 4x(13x24)
U
N
= 830V (525V...830V)
ACA 632-1680-8 4x(13x18) 12 502x280 12 4x(13x24)
ACA 632-3100-8 12x(13x18) 18 502x280 18 4x(13x24)
ACA 632-3520-8 12x(13x18) 18 502x280 18 4x(13x24)
ACA 632-4310-8 12x(13x18) 18 502x280 18 4x(13x24)
