ACS 600 MultiDrive – Technical Data
ACS 600 MultiDrive A-13
Ratings 400 V
The table below shows the nominal ratings for the 400 V range drive
sections.
Type Marking
Nominal Ratings
Duty Cycle
(10 s / 60 s)
Duty Cycle
(1 min / 5 min)
Frame
type
P
loss
kW
Air flow
m
3
/h
Noise
level
dBA
Width
mm
Weight
kg
Notes
S
N
kVA
P
N
kW
I
2N
A
I
2base
A
I
2max
A
I
2base
A
I
2max
A
Drive sections (380...500 V Range, U
N
= 400 V)
ACA 610-05/00/00-3 5 3 7.6 6.2 12 6.2 9.3 R2i 0.08 40 48 400 170 1
ACA 610-05/05/00-3 2xR2i 0.16 80 50 400 or 600 210 1, 6
ACA 610-05/05/05-3 3xR2i 0.24 120 51 400 or 600 220 1, 6
ACA 610-06/00/00-3 6 4 11 7.6 15 7.6 11 R2i 0.09 40 48 400 170 1
ACA 610-06/06/00-3 2xR2i 0.18 80 50 400 or 600 210 1, 6
ACA 610-06/06/06-3 3xR2i 0.27 120 51 400 or 600 220 1, 6
ACA 610-09/00/00-3 9 5.5 15 11 22 11 17 R2i 0.14 40 48 400 170 1
ACA 610-09/09/00-3 2xR2i 0.28 80 50 400 or 600 210 1, 6
ACA 610-09/09/09-3 3xR2i 0.42 120 51 400 or 600 220 1, 6
ACA 610-11/00/00-3 11 7.5 18 15 30 15 23 R3i 0.17 60 48 400 180 1
ACA 610-11/11/00-3 2xR3i 0.34 120 50 400 or 600 220 1, 6
ACA 610-11/11/11-3 3xR3i 0.51 180 51 400 or 600 230 1, 6
ACA 610-16/00/00-3 16 11 24 18 36 18 27 R3i 0.24 60 48 400 180 1
ACA 610-16/16/00-3 2xR3i 0.48 120 50 400 or 600 220 1, 6
ACA 610-16/16/16-3 3xR3i 0.72 180 51 400 or 600 230 1, 6
ACA 610-020/000-3 20 15 32 24 48 24 36 R4i 0.30 70 54 400 190 1
ACA 610-020/020-3 2xR4i 0.60 140 54 400 or 600 240 1, 6
ACA 610-025/000-3 25 18.5 41 32 64 32 48 R4i 0.38 100 54 400 190 1
ACA 610-025/025-3 2xR4i 0.76 200 54 400 or 600 240 1, 6
ACA 610-030/000-3 30 22 47 41 82 41 62 R5i 0.45 260 54 400 190 1
ACA 610-030/030-3 2xR5i 0.90 520 54 400 or 600 240 1, 6
ACA 610-040/000-3 40 30 62 47 94 47 71 R5i 0.60 260 54 400 190 1
ACA 610-040/040-3 2xR5i 1.20 520 54 400 or 600 240 1, 6
ACA 610-050/000-3 50 37 76 62 124 62 93 R5i 0.75 260 54 400 190 1
ACA 610-050/050-3 2xR5i 1.50 520 54 400 or 600 240 1, 6
ACA 610-060/000-3 60 45 89 76 152 76 114 R6i 0.90 480 64 400 200 1
ACA 610-060/060-3 2xR6i 1.80 960 68 600 250 1
ACA 610-070/000-3 70 55 112 89 178 89 134 R6i 1.05 480 64 400 200 1
ACA 610-070/070-3 2xR6i 2.10 960 68 600 250 1
ACA 610-100/000-3 100 75 147 112 224 112 168 R7i 1.50 480 64 400 200 1
ACA 610-100/100-3 2xR7i 3.00 960 68 600 250 1
ACA 610-120/000-3 120 90 178 147 294 147 221 R7i 1.80 480 64 400 200 1
ACA 610-120/120-3 2xR7i 3.60 960 68 600 250 1
ACA 610-0185-3 180 135 259 178 356 194 291 R8i 2.70 1550 61 600 250 2
ACA 610-0225-3 220 165 312 216 432 234 351 R8i 3.30 1550 61 600 250 2
ACA 610-0265-3 260 200 379 260 520 284 426 R8i 3.90 1550 61 600 250 2
ACA 610-0335-3 330 250 474 316 632 356 533 R9i 4.95 1550 61 600 270 2
ACA 610-0405-3 400 315 576 395 790 432 648 R9i 6.00 1550 61 600 270 2
ACA 610-0500-3 500 400 720 494 988 540 810 R10i 7.50 3100 66 1000 450 2
ACA 610-0630-3 630 500 907 600 1200 680 1020 R11i 9.45 3100 66 1000 480 2
ACA 610-0765-3 760 630 1094 751 1502 821 1231 R11i 11.40 3100 66 1000 480 2
ACA 610-0935-3 930 - 1336 901 1802 1002 1503 R12i 13.95 4650 69 1500 950 3
ACA 610-1125-3 1120 - 1624 1126 2252 1218 1827 R12i 16.80 4650 69 1500 950 3
ACA 610-1440-3 1440 - 2079 1501 3002 1559 2339 2xR11i 21.60 6200 69 2x1000 1200 3, 5
ACA 610-1775-3 1770 - 2558 1801 3602 1919 2878 2xR12i 26.55 9300 71 2x1500 1900 4
ACA 610-2145-3 2140 - 3085 2252 4504 2314 3471 2xR12i 32.10 9300 71 2x1500 1900 4
ACA 610-2340-3 2340 - 3374 2402 4804 2531 3796 4xR11i 35.10 12400 71 4x1000 2400 4
ACA 610-2820-3 2820 - 4070 3002 6004 3053 4579 4xR11i 42.30 12400 71 4x1000 2400 4
PDM code 00004863-C
