ACS 600 MultiDrive – Technical Data
A-36 ACS 600 MultiDrive
Protection Features Application program dependent features of the ACx 600 are listed
below. available as standard, optional. Not all selections are
available for all types. For more information refer to the appropriate
application program Firmware Manual.
Preprogrammed Warnings: ACS 600 temperature, Motor
Identification Run, Drive Identification Number change, User Macro,
Target position (ACP).
Programmable Automatic Reset Functions (ACS 600 Standard
Application Program only): after overcurrent, overvoltage,
undervoltage and analogue input below minimum value
Information Functions: ACx 600 control firmware package version,
ACx 600 application program version, ACx 600 test date.
Preprogrammed
Faults
Standard
PFC, M/F
Crane
Motion Control
System
Programmable
Fault Functions
Standard
PFC, M/F
Crane
MotionControl
System
Programm.
Supervision
Functions
Standard
PFC, M/F
Crane
Motion Control
System
ACx 600 temperature Analogue input below
minimum value
Speed 2 2 2
Overcurrent Loss of Control Panel Motor current
Short circuit External fault Motor torque 2 2
DC overvoltage Motor
overtemperature
Motor speed
Supply phase Thermistor/Pt 100 Reference 1
DC undervoltage Motor stalled Reference 2
Overfrequency Motor underload Actual value 1
Loss of Control Panel Loss of motor phase Position error
Internal fault Earth fault Synchron
error
Internal fault on the
I/O control board
Speed measurement Position
threshold
4
Ambient temperature Motor overspeed Joystick
User Macro Torque Brake long
falling time
Braking chopper (in
fieldbus mode)
Torque proving
Inverter overload Master/Follower
communication
No motor data Brake
ID Run fail Communication test
Motor fan control and
diagnostics
Following error
Position limits
Communication error
Encoder interface
module
Overspeed
