ACS 600 MultiDrive – Technical Data
ACS 600 MultiDrive A-11
Dimensions and
Weights 830 V
The table below shows the dimensions and weights of the 830 V
supply sections. See notes on page A-2.
Type Marking Height
mm
Bottom Entry:
Width
mm
To p En t r y :
Width
mm
Depth
mm
Bottom
Entry:
Weight
kg
To p
Entry:
Weight
kg
Width
(EMC)
mm
Weight
(EMC)
kg
Thyristor supply sections (830 V)
ACA 632-1680-81-xx 2130 2200 (600+400+600+600) 2200 (600+400+600+600) 600 1500 1500 ––
ACA 632-3100-81-xx 2130 2200 (600+400+600+600) 2200 (600+400+600+600) 600 1500 1500 ––
ACA 632-3520-81-xx 2130 2200 (600+400+600+600) 2200 (600+400+600+600) 600 1900 1900 ––
ACA 632-4210-81-xx 2130 2200 (600+400+600+600) 2200 (600+400+600+600) 600 1900 1900 ––
Asymmetrical thyristor supply sections (525...830 V Range, U
N
= 830 V)
ACA 632-3100/1680-81-xx 2130 2200 (600+400+600+600) 2200 (600+400+600+600) 600 1500 1500 ––
ACA 632-3520/1680-81-xx 2130 2200 (600+400+600+600) 2200 (600+400+600+600) 600 1900 1900
ACA 632-4310/1680-81-xx 2130 2200 (600+400+600+600) 2200 (600+400+600+600) 600 1900 1900 ––
12 pulse thyristor supply sections (525...830 V Range, U
N
= 830 V)
ACA 636-3190-81-xx 2130 4600 4600 600 3100 3100 ––
ACA 636-5890-81-xx 2130 4600 4600 600 3100 3100
ACA 636-8190-81-xx 2130 4600 4600 600 3100 3100 ––
12/6 pulse thyristor supply sections (525...830 V Range, U
N
= 830 V)
ACA 637-3190-81-xx 2130 4000 4000 600 2900 2900 ––
ACA 637-5890-81-xx 2130 4000 4000 600 2900 2900
ACA 637-8190-81-xx 2130 4000 4000 600 2900 2900 ––
PDM code 00001749-C
