ACS 600 MultiDrive – Technical Data
A-26 ACS 600 MultiDrive
Supply DC Fuses Below are listed Bussmann d.c. fuses used in the thyristor supply
section of ACS MultiDrive frames B1, B2 and B3.
Thyristor Supply
Section
Fuse
U
N
(V)
I
N
(A)
Pre-arching Integral
(A
2
s)
Type Size
400 V and 500 V Supply
ACA 632-0015-31-xx
ACA 632-0020-51-xx
ACA 632-0030-31-xx
ACA 632-0035-51-xx
1250 63 170M4722 1*
ACA 632-0040-31-xx
ACA 632-0050-51-xx
1250 100 170M4724 1*
ACA 632-0070-31-xx
ACA 632-0090-51-xx
1250 160 1900 170M4699 1*
ACA 632-0140-31-xx
ACA 632-0175-51-xx
1250 315 13000 170M5140 2
ACA 632-0200-31-xx
ACA 634-0200-31-xx
ACA 632-0250-51-xx
ACA 634-0250-51-xx
1250 400 23000 170M5142 2
ACA 632-0300-31-xx
ACA 632-0375-51-xx
1250 630 115000 170M5146 2
ACA 632-0420-31-xx
ACA 634-0420-31-xx
ACA 636-0800-31-xx
ACA 638-0800-31-xx
ACA 639-0800-31-xx
ACA 632-0525-51-xx
ACA 636-1000-51-xx
ACA 638-1000-51-xx
ACA 639-1000-51-xx
1250 800 245000 170M5148 2
690 V Supply
ACA 632-0090-61-xx
ACA 633-0180-61-xx
ACA 632-0175-61-xx
ACA 633-0350-61-xx
1250 200 3800 170M4139 1
ACA 632-0250-61-xx 1250 315 13000 170M5140 2
ACA 632-0375-61-xx 1250 400 23000 170M5142 2
ACA 632-0525-61-xx
ACA 636-1000-61-xx
1250 630 115000 170M5146 2
PDM code 000010321-K
