ABB ACS310 User Manual

314 Fault tracing
2008 PANEL LOSS
0308 bit 7
(programmable
fault function 3002)
Control panel selected
as active control
location for drive has
ceased
communicating.
Check panel connection.
Check fault function parameters.
Check control panel connector.
Refit control panel in mounting
platform.
If drive is in external control mode
(REM) and is set to accept start/stop,
direction commands or references
through control panel:
Check group 10 START/STOP/DIR
and 11 REFERENCE SELECT
settings.
2009 DEVICE
OVERTEMP
0308 bit 8
Drive IGBT
temperature is
excessive. Alarm limit
is 120 °C.
Check ambient conditions. See also
section Derating on page 338.
Check air flow and fan operation.
Check motor power against drive
power.
2010 MOTOR TEMP
0308 bit 9
(programmable fault
function
3005…3009 / 3503)
Motor temperature is
too high (or appears to
be too high) due to
excessive load,
insufficient motor
power, inadequate
cooling or incorrect
start-up data.
Check motor ratings, load and
cooling.
Check start-up data.
Check fault function parameters.
Measured motor
temperature has
exceeded alarm limit
set by parameter 3503
ALARM LIMIT.
Check value of alarm limit.
Check that actual number of sensors
corresponds to value set by
parameter 3501 SENSOR TYPE.
Let motor cool down. Ensure proper
motor cooling: Check cooling fan,
clean cooling surfaces, etc.
2012 MOTOR STALL
0308 bit 11
(programmable fault
function
3010…3012)
Motor is operating in
stall region due to eg
excessive load or
insufficient motor
power.
Check motor load and drive ratings.
Check fault function parameters.
2013
1)
AUTORESET
0308 bit 12
Automatic reset alarm Check parameter group 31
AUTOMATIC RESET settings.
2014
1)
AUTOCHANGE
0308 bit 13
PFC Autochange
function is active.
See parameter group 81 PFC
CONTROL, section PFC control
macro on page 110 and section
SPFC control macro on page 111.
2015 PFC I LOCK
0308 bit 14
PFC Interlocks are
active.
Drive cannot start
• any motor (when Autochange is
used)
• the speed regulated motor (when
Autochange is not used).
See parameter group 81 PFC
CONTROL.
2018
1)
PID SLEEP
0309 bit 1
Sleep function has
entered sleeping
mode.
See parameter groups 40 PROCESS
PID SET 1… 41 PROCESS PID SET
2.
CODE ALARM CAUSE WHAT TO DO
