ABB ACS310 User Manual

86 Control panels
 Output mode
In the Output mode, you can:
• monitor actual values of up to three signals in group 01 OPERATING DATA
• change the direction of the motor rotation
• set the frequency reference
• adjust the display contrast
• start, stop, change the direction and switch between local and remote control.
You get to the Output mode by pressing repeatedly.
The top right corner of the
display shows the reference
value. The center can be
configured to show up to three
signal values or bar graphs; see
page 89 for instructions on
selecting and modifying the monitored signals.
How to change the direction of the motor rotation
Step Action Display
1. If you are not in the Output mode, press repeatedly
until you get there.
2. If the drive is in remote control (REM shown on the status
line), switch to local control by pressing . The display
briefly shows a message about changing the mode and
then returns to the Output mode.
3. To change the direction from forward ( shown on the
status line) to reverse ( shown on the status line), or
vice versa, press .
Note: Parameter 1003 DIRECTION must be set to 3
(REQUEST).
EXIT
DIR MENU
00:00
LOC
49.1Hz
49 1 Hz.
05 A.
10 7 %.
DIR MENU
00:00
LOC
5.0Hz
04 A.
24 4 %.
Hz 50%
EXIT
DIR MENU
00:00
REM
49.1Hz
49 1 Hz.
05 A.
10 7 %.
LOC
REM
DIR
MENU
00:00
LOC
49.1Hz
49 1 Hz.
05 A.
10 7 %.
DIR
DIR MENU
00:00
LOC
49.1Hz
49 1 Hz.
05 A.
10 7 %.
