Advant Controller 450 Product Guide
Section 3.1 Basic Program Module, QC07-BAS41
3BSE 015 953R201 Rev B 3-1
Chapter 3 Software Components
Advant Controller 450 system software comprises a real-time operating system and an
AMPL execution machine.
The functional extent of Advant Controller 450 is determined by adding optional software and
hardware units to the basic unit. The software options are delivered as program modules which
may be selected to create the desired functional configuration. Optional hardware units are I/O
and communication modules etc.
The software system for Advant Controller 450 is built around one Basic program module to
which Optional alternative program modules can be added. The Optional program modules can
be combined in a number of combinations needed to solve the application task. A description of
the program modules and a specification of their contents is given below. The Basic program
module, QC07-BAS41, together with the optional software below are stored in one program
card, placed on the CPU PM511V.
3.1 Basic Program Module, QC07-BAS41
The Basic program module has the following functional contents:
• Logic control and time delays
• Arithmetic
• Data and text handling
• Sequence control
• Calendar time functions
• Table handling
• Fast pulse counting and frequency measurement
• Positioning
• Reports
• Functional units, binary
1
• Functional units, analog
1
• Functional units, motor and valve control, group start
1
• Support for MasterBus 300/300E
• Support for GCOM
• Support for RCOM/RCOM+
1. The PC elements and database parts of the functional units are included in the Basic program module.
The presentation and dialog support require the optional Program Module QC07-OPF41. Special dedicated
interface boards are not included in the system unit.
