Advant Controller 450 Product Guide
Section 3.7 Optional Program Module, QC07-BAT41
3BSE 015 953R201 Rev B 3-7
3.7 Optional Program Module, QC07-BAT41
The Optional program module QC07-BAT41 extends the functionality of the controller with
support for connecting it to the batch station MasterBatch 200/1.
MasterBatch 200/1 is connected to Advant Controller 450 through MasterNet.
3.8 Optional Program Module, QC07-UDP41
The Optional program module QC07-UDP41 makes it possible to execute user defined
PC elements in the Advant Controller 450. The user defined PC element is created in AMPL
Control Configuration (1.7 or a later product version) and built-up of a combination of normal
PC elements from the standard PC element libraries of the Advant Controller 450. After the user
defined PC element is installed in the Advant Controller 450 it can be used freely in all
PC programs as a normal PC element.
3.9 Optional Program Module, QC07-COM41
The optional program module QC07-COM41 can provide AIS, DIS, MB, MI, MIL and MR
objects in Advant Controller 110/160 to be operated from an operator station such as
Advant Operator Workplace or AdvaSoft for Windows.
Following functions are supported:
• Acknowledgment of events
• Blocking of events and alarms
• Blocking of process data update
• Blocking of process data value
The function is realized with PC elements in Table 3-7.
Table 3-7. Additional PC elements in program module QC07-COM41
Type PC element
Elements for object support COM-AIS, COM-DIS, COM-M
