Advant Controller 450 Product Guide
Section 6.11 Program Module Size on Program Card
3BSE 015 953R201 Rev B 6-15
6.11 Program Module Size on Program Card
When stored on the program card, the program modules occupy the following memory areas.
Basic requirements for QC07-FUZ41 1 x 40
Basic requirements for QC07-COM41 1 x 33
Basic requirements for QC07-BAS41 1 x 2207
Spare RAM area
(8)
1x 4040
Approximative total RAM requirement in kbytes
(9)
(1) The figures are calculated for 8 steps (MOTCON not included).
(2) The figures are calculated for 1 table with 10 rows and 100 values per row.
(3) The figures are calculated for 40 text strings with 20 characters and 30 dynamic values.
(4) The figures apply to 100 events per list.
(5) The figures are calculated for 1 log with 10 variables, each with 240 stored values. Each value takes approximately 5 byte.
(6) The figures are calculated for 50 storage vessels, 4 sections and 20 operations with 6 recipe variables each.
(7) This is a recommended starting value. Adjustment of this figure might be necessary to do when the real need is known.
(8) Recommended value for most systems.
(9) Must be less than the RAM size of the processor module (8 or 16 Mbyte).
Table 6-15. Program module memory area on program card
Program module Memory area (kbyte)
QC07-BOB41 9
QC07-BAS41 1410
QC07-LIB41 32
QC07-LIB42 405
QC07-OPF41 550
QC07-LOS41 205
QC07-BAT41 279
QC07-UDP41 85
QC07-COM41 20
QC07-FUZ41 40
Table 6-14. Calculation of RAM requirement (Continued)
Object type Remark Total
Factor
(kbytes)
RAM req.
