Chapter 3 Software Components
3-2 3BSE 015 953R201 Rev B
• Support for MultiVendor Interface
• Support for fieldbus communication (Advant Fieldbus 100, PROFIBUS-DP, L
ONWORKS
Network, MasterFieldbus).
• Strain-gauge weighing support
• Support for motor drives
• Data Set/DAT communication
• Back-up of application program in flash-PROM card
Most of the above mentioned functions are realized with one or several PC elements.
The contents of the PC element library in the basic program module is shown in Table 3-1.
Table 3-1. PC elements in the basic program module QC07-BAS41
Type PC element
Structure elements PCPGM, CONTRM, FUNCM, MASTER, SLAVEM,
BLOCK, SEQ, STEP
Logic elements AND, OR, AND-O, OR-A, XOR, INV, SR, SR-D, SR-AA,
SR-AO, SR-OO, SR-OA
Arithmetic elements ADD, SUB, MUL, DIV, ADD-MR1, ADD-MR,
DIV-MR, SQRT, ABS, LIM-N
Time delays TON, TOFF, MONO, TON-RET, TRIGG, OSC-B
Calendar time elements TIME, DATE, TIMER
Registers SHIFT, SHIFT-L, FIFO, REG-RET, EXPAND, EXPAND-
A, FIFO-RW, REG, REG-G
Multiplexers MUX-I, MUX-N, MUXA-I, MUX-MI, MUX-MN,
DEMUXA-M, DEMUX-MI
Code converters CONV-BI, CONV-IB, CONV-AI, CONV-IA,
CONV-SA, CONV
Counters COUNT, COUNT-L
Comparators COMP-I, COMP-R, COMP, MAX, MIN
Fault elements FAULT
Printing and text generation
elements
TEXT, PRINT
Elements for functional
units
GENBIN-I, GENBIN-O, GENUSD-I, GENUSD-O, GEN-
CON-I, GENCON-O, MOTCON,
VALVECON, MMC-IND, MMC-ORD
Switches SW, SW-C
Positioning elements POS-A, POS-O, POS-L
