Advant Controller 450 Product Guide
Chapter 6 Technical Data and Performance
6-6 3BSE 015 953R201 Rev B
6.5.3 Communication Buses
Various buses in accordance with Table 6-5 can be connected to the Advant Controller 450.
Table 6-5. Number of buses/channels that can be connected to Advant Controller 450
Bus type Max number of buses
MasterBus 300 (executed in main CPU) 2 Tot
2
(1)
(1) MasterBus 300 in main CPU and MasterBus 300E in slave CPU can not be mixed in the same
controller. MasterBus 300 in slave CPU and MasterBus 300E in main CPU can not be mixed within
the same controller.
MasterBus 300E (executed in main CPU) 2
MasterBus 300 (executed in slave CPU) 6 Tot
6
(1)
MasterBus 300E (executed in slave CPU) 6
GCOM 5 Tot
9
RCOM/RCOM+ 9
Multivendor Interface 9
Telecontrol & SPA Bus 5
MasterFieldbus 7
Advant Fieldbus 100 8
(2)
(2) If single bus is used: 1 submodule/bus. If redundant bus is used: 2 submodules/bus
Tot
8
PROFIBUS-DP 8
L
ONWORKS Network 8
EXCOM 2
Table 6-6. Submodules mounted in submodule carriers
Description Submodule
No. of
channels per
submodule
Fits into
submodule
carrier
Max. No.
of sub-
modules
(1)
RS-232-C communication CI531 2 SC510, SC520 4
(2)
MasterBus 300 (executed in main
CPU)
CS513 1 SC510,
SC520
(3)
2
(4),(5)
MasterBus 300E
(executed in main CPU)
CS513 1 SC510,
SC520
(3)
2
(4)(5)
MasterBus 300
(executed in slave CPU)
CS513 1 SC520 6
(4)
MasterBus 300E
(executed in slave CPU)
CS513 1 SC520 6
(4)
PROFIBUS-DP CI541V1 1 SC510, SC520 8
(6)
