ABB Advant Controller 450 Product Guide

Advant Controller 450 Product Guide
Section 5.1 Cabinet Design
3BSE 015 953R201 Rev B 5-1
Chapter 5 Mechanical Design
5.1 Cabinet Design
Advant Controller 450 with S100 I/O is mounted in a cabinet in a standardized way.
Depending on the mixture of I/O boards, modems, power supplies, etc. to be used,
some variations can occur.
Figure 5-1 shows an example of the arrangement of a controller in two cabinets.
NOTE
Two different cabinet versions are used, RM500V1 and RM500V2. Please refer
to Table 6-20 for definitions and dimensions.
Figure 5-1. Typical Advant Controller 450 with S100 I/O
Mains Net Filter
(CE-marked
Versions Only)
Controller Subrack
Power Supply
(SA16x)
Power Switch
and Distribution
Field Power Supply
(SA16x)
I/O Subrack
Connection Units
Modem Subrack
