Advant Controller 450 Product Guide
Section 6.3.1 Connection Unit Dimensions
3BSE 015 953R201 Rev B 6-3
6.3.1 Connection Unit Dimensions
The width of the connection units are given in Table 6-3 below.
Table 6-3. The Width of the Connection Units
Connection Unit
Width in
mm inch
DSTA 001A 240 9.4
DSTA 001B 240 9.4
DSTA 002A 240 9.4
DSTA 002B 240 9.4
DSTA 131 240 9.4
DSTA 133 240 9.4
DSTA 135 240 9.4
DSTA 137 470 18.5
DSTA 138 470 18.5
DSTA 145 240 9.4
DSTA 155 240 9.4
DSTA 155P 160 6.3
DSTA 156 240 9.4
DSTA 156B 120 4.7
DSTA 160 80 3.2
DSTA 170 160 6.3
DSTA 171 120 4.7
DSTA 180 240 9.4
DSTA 181 120 4.7
DSTD 108 120 4.7
DSTD 108L 120 4.7
DSTD 108LP 120 4.7
DSTD 108P 120 4.7
DSTD 109P 120 4.7
DSTD 110A 240 9.4
