8.6.11 Power Supply System
Ribbon cable with connectors for connecting
EP532 or 533 to modem DSTC X008,
0.5 m (20”)
DSTK156V0.5 26390638-A
Cable assembly RS-232C
DE9 socket to DB25 pin For connection of
printer to CI531, length 15 m (49 ft.)
TK520V150 3BSC950019R2
Table 8-29. Power Supply in RM500V1 Cabinet, 120V a.c. Mains
Description Consists of Article No.
Single a.c. mains supply (SA167K01)
for controller subrack and I/O subrack 1
Input: 120 V a.c., 50/60 Hz
Output: 24 V, 25 A, d.c., unregulated
SA167
SX554
SX540
TK402V014
3BSE003573R1
Red. a.c. mains supply (SA167K03)
for controller subrack and I/O subrack 1
Input: 120 V a.c., 50/60 Hz
Output: 24 V, 25 A, d.c., unregulated
2xSA167
2xSX554
2xSX540
2xTK402V014
TK451
3BSE003579R1
a.c. mains supply (SA161K10)
for I/O subrack 2 Input: 120 V a.c., 50/60 Hz
Output: 24 V, 10 A, d.c., unregulated
SA161
SX554
TK402V051
3BSE008781R1
a.c. mains supply (SA167K13) for I/O subrack
2 and 3 Input: 120 V a.c., 50/60 Hz
Output: 24 V, 25 A, d.c., unregulated
SA167
SX554
TK402V051
3BSE008785R1
a.c. mains supply (SA161K11)
for I/O subrack 4 Input: 120 V a.c., 50/60 Hz
Output: 24 V, 10 A, d.c., unregulated
SA161
SX554
TK402V060
3BSE008782R1
a.c. mains supply (SA167K14) for I/O subrack
4 and 5 Input: 120 V a.c., 50/60 Hz
Output: 24 V, 25 A, d.c., unregulated
SA167
SX554
TK402V060
3BSE008786R1
Table 8-28. Printers (Continued)
Description Consists of Article No.
