Advant Controller 450 Product Guide
Section 4.6 System Unit
3BSE 015 953R201 Rev B 4-5
4.6 System Unit
The system unit for an Advant Controller 450 consists of the units in Table 4-2.
4.7 I/O Systems
S100 I/O System
The S100 I/O bus extension cable is physically connected directly to the CPU PM511V.
The Reference Guide details the various I/O boards available for Advant Controller 450.
Further information about S100 I/O is given in the Product Guide for S100 I/O.
S800 I/O System
The S800 I/O Station is physically connected to an Advant Controller 450 via
Advant Fieldbus 100. Table 2-1 lists the various I/O modules available for
Advant Controller 450.
Further information about S800 I/O is given in the Product Guide for S800 I/O.
Table 4-2. System unit for Advant Controller 450
Units Description
RF533 Controller subrack
RC527 Fan unit
SR511
(1)
(1)One SR511 can feed all modules in part A below.
Voltage regulator
TC520 Supervision unit
Table 4-3. S100 I/O Bus Extensions
Having CPU
Needing S100 I/O Bus
Extension
Then use Connection Kit
Single CPU
1 x PM511V
Single Bus Extension
1 x DSBC 176
Kit for single S100 I/O
Bus Extension
Redundant CPU
2 x PM511V
Single Bus Extension
1 x DSBC 176
Kit for single S100 I/O
Bus Extension
Kit containing 2 x TK589,
TK566
Redundant CPU
2 x PM511V
Redundant Bus Extension
2 x DSBC 174
Kit for redundant S100I/O
Bus Extension
