Advant Controller 450 Product Guide
Section 3.1 Basic Program Module, QC07-BAS41
3BSE 015 953R201 Rev B 3-3
Besides the PC element library, the basic program module also includes a functional unit library.
The functional units supplement the PC elements and they are primarily intended for realizing
instrumentation functions. The contents of the functional unit library is shown in Table 3-2.
Pulse counting and fre-
quency measurement
elements
PULSE-S, COUNT-DP, FREQ-SP, FREQ-MP, PCU-I,
PCU-O, PCU-COM, PCU-SS
Data handling elements MOVE, MOVE-A
Event handling element EVENT
Report element REPORT
Elements for programma-
ble module
FPM-COM, FPM-I, FPM-IA, FPM-O, FPM-OA
Weighing elements SCALE, SCALEDOS
Table handling elements TBL-R, TBL-RG, TBL-W, TBL-WG
Ramp generators RAMP-S1
Supervision elements ANALYSE, COM-STAT
MasterFieldbus
communication elements
COM-MP51, MFB-OUT, MFB-IN, COM-CVI1, COM-
CVO1
Advant Fieldbus 100
communication elements
DSP-R, DSP-S, DRI-CNV, DRI-R, DRI-S
PROFIBUS-DP
communication elements
PB-DIAG, PB-R, PB-S
L
ONWORKS Network
Interface
communication elements
LON-R, LON-S
Data Set elements SENDREQ
Table 3-2. Functional units in the base program module QC07-BAS41
Functional unit Description
AI Analog input signal, including AI, Temp. (Pt100), TC (thermo-
couple), and AIC (calculated AI).
AO Analog output signal, including AO and AOC (calculated AO)
DI Digital input signal, including DI and DIC (calculated DI)
DO Digital output signal, including DO and DOC (calculated DO)
Table 3-1. PC elements in the basic program module QC07-BAS41 (Continued)
Type PC element
