Chapter 6 Technical Data and Performance
6-16 3BSE 015 953R201 Rev B
6.12 Controller Subrack
The subrack, RF533, is divided into three parts, as shown in Figure 6-1.
The number of slots in the controller subrack is shown in Table 6-16.
Part A can be filled with modules from Table 6-17 while part B and C has dedicated slots for
the modules and units in Table 6-18.
The submodule carriers can be equipped with submodules from Table 6-6.
Figure 6-1. The division of the controller subrack
Table 6-16. The No. of slots in the controller subrack
Part No. of slots
Part A 8
Part B 5
Part C 5
Table 6-17. Modules that can go into part A of the controller subrack
Description Consists of Max modules
(1)
(1) The total number of modules in part A may not exceed 8
Processor module PM511V 2
Submodule carrier without CPU SC510 7
Submodule carrier with slave CPU for MB 300/300E SC520 6
Module for AccuRay QCS PM511V
(2)
(2) Please refer to AccuRay QCS documentation
Table 6-18. Modules placed in part B and C of the controller subrack
Description Consists of
Max no
of modules
Slots /
module
Placed
in part
Voltage regulator SR511 2 2 B
Back-up power supply SB510/511 2 2 C
Supervision unit TC520 1 1 C
Part A
Part B
Part C
