ABB CL Series User Manual

Wiring with the display system
132
1SVC 440 795 M1100
A contact of a function relay is assigned the name of the
function block, the number and the contact function.
Example: Contact of comparator function block
If the contact on a network station is used, the address of the
station is placed before the contact name.
Example: Contact of a CL-NET station
Coils
For a relay coil or function block select the coil function, coil
or function block name, coil function block number and coil
of the function block. For the coils of a CL-NET station you
select the network address before the coil name.
Example: Relay coil output
Relay coil for timing relay function block with control coil
Relay coil of a CL-NET network station
CP01GT
Contact name
Contact number
Contact function
2RN02
Station address
Contact name
Contact number
S Q 04
Coil function
Coil name
Coil number
Ä T 04EN
Coil function
Coil name
Coil number
Function block coil
S2SN04
Coil function
Station address
Coil number
Coil name
h
A full list of all the contacts and relays is given in the
overview starting on page 116.
