2 Installation and commissioning
2.5.11. Installation of cooling fan for motors, axes 1-3 (option)
1053HAC022033-001 Revision: K
© Copyright 2004-2011 ABB. All rights reserved.
xx0700000671
Cooling fan
The details of the cooling fan are shown in the figure below.
xx0500002158
A Cooling fan, axis 2
B Cooling fan, axis 1
C Rear cover plate
A Fanbox
B Attachment screws, fanbox plates (9 pcs)
C Groove in the connector
D Tightening screws, fanbox (3 pcs)
Continued
Continues on next page
