3 Maintenance
3.4.6. Oil change, gearbox, axis 5
3HAC022033-001 Revision: K214
© Copyright 2004-2011 ABB. All rights reserved.
Filling, oil, gearbox axis 5
The procedure below details how to fill oil in gearbox, axis 5.
When using the oil exchange equipment, follow the instructions enclosed with the kit. Art.
no. for the kit is specified in Required equipment on page 213.
Action Note
1.
WARNING!
Handling gearbox oil involves several safety risks.
Before proceeding, please read the safety
information in the section WARNING - Safety risks
during work with gearbox lubricants (oil or grease) on
page 51.
2.
DANGER!
Turn off all electric power, hydraulic and pneumatic
pressure supplies to the robot!
Turn off all electric power and hydraulic but not the air
pressure to the gearboxes, motors and SMB.
3. Refill the primary gearbox with lubricating oil through
the oil plug, filling. Make sure the air is ventilated
through the oil plug during filling, to avoid overpres-
sure in the gearbox.
The amount of oil to be refilled depends on the
amount previously being drained. The correct oil
level is detailed in section Inspection, oil level,
gearbox axis 5 on page 161.
Kyodo Yushi TMO 150
Art. no. and total amount is
specified in Required equipment
on page 213.
Shown in the figure Location of
gearbox on page 212.
4. Refill the secondary gearbox with lubricating
oilthrough the oil plug, filling.
The amount of oil to be refilled depends on the
amount previously being drained. The correct oil
level is detailed in section Inspection, oil level,
gearbox axis 5 on page 161.
Kyodo Yushi TMO 150
Art. no. and total amount is
specified in Required equipment
on page 213.
Shown in the figure Location of
gearbox on page 212.
5.
WARNING!
Do not mix oil types! If wrong oil is refilled, the
gearbox must be rinsed as detailed in section Type of
oil on page 192.
6. Refit the both oil plugs, filling. Shown in the figure Location of
gearbox on page 212.
Tightening torque: 24 Nm.
Continued
