8 Spare part / part list
8.3.3. Part list, overview
3HAC022033-001 Revision: K440
© Copyright 2004-2011 ABB. All rights reserved.
103 1 3HAC16628-4
(spare part no.)
Wrist See section Wrist,
3HAC16628-4 /
3HAC16628-3 on page 449.
3HAC16628-3
(spare part no.)
3HAC027295-001
Foundry Prime)
Wrist Insulated tool flange.
See section Wrist,
3HAC16628-4 /
3HAC16628-3 on page 449.
104 1 3HAC14675-1 Balancing Device E
105 1 3HAC10523-1 Lower arm
106 1 3HAC14940-1 Cable harness, man. ax1-4 Brake release in frame.
3HAC12782-1 Cable harness, man. ax1-4 Brake release in base.
108 1 3HAC13079-1 Material set manipulator See section Material set
robot, 3HAC13079-1 on
page 455.
109 1 3HAC13077-1 Material set ax 1-2 See section Material set axis
1-2, 3HAC13077-1 on page
456.
110 1 3HAC13082-1 Mtrl.set balancing device See section Material set
balancing device,
3HAC13082-1 on page 459.
111 1 3HAC12311-1 Arm extension set 956mm IRB 7600 - 150/3.5
See section Arm extension
set, 956 mm, 3HAC12311-1
(IRB 7600 - 150/3.5) on page
460.
1 3HAC12311-2 Arm extension set 250mm IRB 7600 - 340/2.8
See section Arm extension
set, 250 mm, 3HAC12311-2
(IRB 7600 - 340/2,8) on page
461.
1 3HAC12311-3 Arm extension set 500 mm IRB 7600 - 325/3.1
See section XREF.
112 1 3HAC17637-1 Cover plate
113 4 or
8
9ADA618-56 Torx pan head screw Steel 8.8-A2F, M6x16
114 1 3HAC13416-1 Protection cover
115 1 3HAC18281-1 Cover
Item Qty Art. number Description Note / Dimension
Continued
To Next Page
