ABB M2000 User Manual

8 Spare part / part list
8.3.10. Wrist, 3HAC16628-4 / 3HAC16628-3
3HAC022033-001 Revision: K450
© Copyright 2004-2011 ABB. All rights reserved.
103.28 1 3HAC024852-002 Axis 6 complete Foundry See table Axis 6
complete Foundry and
standard,
3HAC024852-002 /
3HAC024852-001 on
page 452.
3HAC024852-001 Axis 6 complete standard
3HAC024594-001 Axis 6 insulated See table Axis 6
insulated,
3HAC024594-001 on
page 453.
103.31 1 3HAA2166-24 VK-Cover
103.32 21 3HAB3409-90 Hex socket head cap
screw
M16x90
103.33 1 3HAC022184-001 Wheel unit, tightened See table Wheel unit,
tightened,
3HAC022184-001 on
page 452.
103.34 1 3HAA1001-628 Sealing
103.35 7 9ADA624-56 Torx counters. head screw M6x16
103.37 1 3HAB7116-1 Locking liquid
103.38 1 3HAC11440-5 Heat protection plate
103.39 3 21662055-3 Cable straps, outdoors
103.40 1 3HAC11440-1 Cable harness,manip
ax5-6
103.41 3,800 ml 3HAC032140-001 Lubricating oil:
TMO 150
NOTE! Do not mix with
other oils!
The different types of
oils are further
specified in section Oil
in gearboxes.
103.42 750 ml 3HAC032140-001 Lubricating oil:
Kyodo Yushi TMO 150
103.43 1 3HAC024760-001 Wrist label Foundry
3HAC022183-002/
3HAC16628-4
3HAC024758-001 Wrist label standard
3HAC022183-001/
3HAC16628-4
3HAC024761-001 Wrist label insulated
3HAC024630-001/
3HAC16628-3
103.44 1 3HAC020486-001 Pinion Z3 / 4,5
103.45 1 3HAC020619-001 Set of shims Z3 / 4,5
103.46 9 3HAB3409-71 Hex socket head cap
screw
M12x60
103.47 6 3HAB3409-86 Hex socket head cap
screw
M16x60
Item Qty Art. number Description Note / Dimension
Continued
Continues on next page
