2 Installation and commissioning
2.5.1. Lifting robot with fork lift
3HAC022033-001 Revision: K72
© Copyright 2004-2011 ABB. All rights reserved.
Attachment points on robot
The attachment points for the fork lift equipment are shown in this figure.
xx0400000707
Required equipment
To determine which fork lift set to use, see the section Different designs on page 71.
A Attachment points, spacer and horizontal attachment screws
B Attachment points, horizontal attachment screws
C Attachment points, vertical attachment screws
D Attachment points, horizontal attachment screws
Equipment, etc. Art. no. Note
Fork lift set, incl. all required
hardware
3HAC0604-2 See figure Fork lift set, 3HAC0604-2 on
page 73.
Standard toolkit - Content is defined in section Standard
toolkit on page 427.
Continued
Continues on next page
