Softstarters Type PSE18...PSE370 Installation and commissioning manual 1SFC132057M020118 Chapter 3
3.3 Type designation
Type designation to be found on the softstarters front. See gure 3.4.
Softstarter type: PSE
Current rating: 18 = 18 A
Operational voltage: 600 = 208 - 600 V 50/60 Hz
Control supply voltage: 70 = 100 - 250 V 50/60 Hz
3.4 Documentation
Documentation such as brochures, catalogs, certicates, and drawings included
can be found at: www.abb.com/lowvoltage. Select the link Control Products and
then continue to Softstarters.
3.5 Environmental inuence
The product is designed to minimize the environmental effects during manufactur-
ing and use of the product. Most of the materials used, are of recycle type, and
shall be handled and recycled according to existing laws.
Further information regarding used material and recycling of the product can be
found at: www.abb.com/lowvoltage
Degree of protection
(Operational circuit)
IP 00
Operating position Vertical at ±
30
o
Ambient temperature Storage. -40
o
C to + 70
o
C (-40
o
F to 158
o
F)
Operation: -25
o
C to + 40
o
C (-13
o
F to 104
o
F) without
derating.
+ 40
o
C to + 60
o
C (104
o
F to 140
o
F) with derating 0.6
% /1
o
C (0.6% / 1,8
o
F).
Altitude 1000 m (3281 ft.) above sea level without derating.
1000-4000 m (3281 - 13123 ft.) above sea level with
derating
0.007% / m.
Pollution degree 3
Relative humidity 5-95% (non-condensing)
Standards IEC 60947-1
IEC 60947-4-2
EN 60947-1
EN 60947-4-2
Standards
UL 508, CSA C22.2 No 14-10
3.6 Specications
Table 3.1
PSE18 - 600 - 70
A
B
C
D
Figure 3.4: Type designation
A
B
C
D

ABB PSE 18 Specifications

General

Brand	ABB
Model	PSE 18
Category	Controller
Language	English
