Softstarters Type PSE18...PSE370 Installation and commissioning manual 1SFC132057M020180 Chapter 8
Chapter 8 Fieldbus communication
8.1 Overview
The PSE Softstarter has an interface on the front for connecting the ABB Field-
BusPlug used for eldbus communication. Through this interface it is possible to
control the softstarter, retreive status information, as well as upload and download
of parameters.
The interface between the softstarter and the FieldBusPlug is independent of
the eldbus protocol used. Independent of softstarter size or delivery date it is
possible to connect any of the available Fieldbus protocols later on, since this is
dened in the FieldBusPlug itself.
The following Fieldbus protocols are available:
• DeviceNet
• CANopen
• Probus
• Modbus
More information about the installation of eldbus communication is available in
chapter 7.5.12 FieldBus Control (optional hardware required).
8.1.1 Required accessories
To connect the PSE Softstarter to a eldbus system, the following accessories are
required:
• ABB FieldBusPlug Accessory FBPA
• ABB FieldBusPlug for present eldbus protocol (check that the cable length is
sufcient).
• Connectors for bus connection.
• End plug (some protocols).
• Software for PLC set-up.
8.1.2 Instructions
To do the set-up of input and output telegrams, parameter settings, instructions,
etc. are available at: www.abb.com/lowvoltage :
• DeviceNet 1SFC132066M0201
• Probus DP 1SFC132067M0201
• Modbus 1SFC132068M0201
• CANopen 1SFC132069M0201
Figure 8.1: Principle of a eldbus network with
PSE Softstarters connected
PSE 18-600-70 PSE 18-600-70
