Softstarters Type PSE18...PSE370 Installation and commissioning manual 1SFC132057M0201 21 Chapter 3
3.7.4 IEC information
Equipment suitable for use in a circuit with maximum available fault current as
shown when protected by devices indicated in table 3.8. Examples of semicon-
ductor fuses and MCCB according to IEC. For more information about fuses see:
http://www.abbcontrol.fr/coordination_tables/coordtable.htm
Table 3.8
Softstarter
Type
IEC
Type 2 co-ordination
Fuses
Type 1 co-ordination
MCCB
MCCB
600V
Iq 85kA
400V
Iq 35kA
400V
Iq 50kA
Semicond. Bussmann
DIN 43620
Type Rating Type Type
PSE18-600-70 170M1563 40A T2N160 MA20
T2S160 MA20
PSE25-600-70 170M1564 50A T2N160 MA32
T2S160 MA32
PSE30-600-70 170M1566 80A T2N160 MA52
T2S160 MA52
PSE37-600-70 170M1567 100A T2N160 MA52
T2S160 MA52
PSE45-600-70 170M1568 125A T2N160 MA52
T2S160 MA52
PSE60-600-70 170M1569 160A T2N160 MA80
T2S160 MA80
PSE72-600-70 170M1571 250A T2N160 MA80
T2S160 MA80
PSE85-600-70 170M1572 315A T2N160 MA100
T2S160 MA100
PSE105-600-70 170M3819 400A
T3N250 MA160 T3S250 MA160
PSE142-600-70 170M5809 450A
T3N250 MA200 T3S250 MA200
PSE170-600-70 170M5810 500A
T3N250 MA200 T3S250 MA200
PSE210-600-70 170M5812 630A
T4N320 PR221-I In320 T4S320 PR221-I In320
PSE250-600-70 170M5813 700A
T5N400 PR221-I In400 T5S400 PR221-I In400
PSE300-600-70 170M6812 800A
T5N400 PR221-I In400 T5S400 PR221-I In400
PSE370-600-70 170M6813 900A
T5N630 PR221-I In630 T5S630 PR221-I In630
