Softstarters Type PSE18...PSE370 Installation and commissioning manual 1SFC132057M020120 Chapter 3
Table 3.4
Type PSE 18 PSE 25 PSE 30 PSE 37
Rated Current I
e
(A) 18 25 30 37
Motor size 380 - 415 V (kW) 7.5 11 15 18.5
Motor size 480 V (hp) 10 15 20 25
Motor size 600 V (hp) 15 20 25 30
Power loss at Rated Current (W) 0.2 0.4 0.5 0.8
Power supply requirements holding
(VA)
16 16 16 16
Power supply requirements pull-in
value (VA)
19,9 19,9 19,9 19,9
Table 3.5
Type PSE 45 PSE 60 PSE 72 PSE 85
Rated Current I
e
(A) 45 60 72 85
Motor size 380 - 415 V (kW) 22 30 37 45
Motor size 480 V (hp) 30 40 50 60
Motor size 600 V (hp) 40 50 60 75
Power loss at Rated Current (W) 1.2 2.2 3.1 4.3
Power supply requirements holding
(VA)
16 16 16 16
Power supply requirements pull-in
value (VA)
19,9 19,9 19,9 19,9
Table 3.6
Type PSE 105 PSE 142 PSE 170 PSE 210
Rated Current I
e
(A) 106 143 171 210
Motor size 380 - 415 V (kW) 55 75 90 110
Motor size 480 V (hp) 75 100 125 150
Motor size 600 V (hp) 100 125 150 200
Power loss at Rated Current (W) 6.6 12.1 17.6 8.8
Power supply requirements holding
(VA)
16 16 16 23
Power supply requirements pull-in
value (VA)
19,9 31 31 350
3.7.3 PSE Softstarter types
Table 3.7
Type PSE 250 PSE 300 PSE 370
Rated Current I
e
(A) 250 302 370
Motor size 380 - 415 V (kW) 132 160 200
Motor size 480 V (hp) 200 250 300
Motor size 600 V (hp) 250 300 350
Power loss at Rated Current (W) 12.5 18 27.4
Power supply requirements holding
(VA)
23 23 23
Power supply requirements pull-in
value (VA)
350 350 350
