Function IEC 61850 A B C
Three-phase thermal protection for feeders, cables and distribution
transformers
T1PTTR 1 1 1
Circuit breaker failure protection CCBRBRF 1 1 1
Three-phase inrush detector INRPHAR 1 1 1
Master trip TRPPTRC 2 2 2
Switch onto fault CBPSOF 1 1 1
Control
Circuit-breaker control CBXCBR 1 1 1
Autoreclosing DARREC (1) (1) (1)
Condition monitoring and supervision
Trip circuit supervision TCSSCBR 2 2 2
Logging
Disturbance recorder RDRE 1 1 1
Fault recorder FLTRFRC 1 1 1
Measurement
Three-phase current measurement CMMXU 1 1 1
Sequence current measurement CSMSQI 1 1 1
Residual current measurement RESCMMXU 1 1 1
Three-phase voltage measurement VMMXU 1
Sequence voltage measurement VSMSQI 1
Residual voltage measurement RESVMMXU 1 1
Frequency measurement FMMXU 1
Three-phase power and energy measurement PEMMXU 1
Other
Input switch group ISWGAPC 10 10 10
Output switch group OSWGAPC 21 21 21
Selector SELGAPC 6 6 6
Minimum pulse timer (2 pcs) TPGAPC 10 10 10
Move (8 pcs) MVGAPC 1 1 1
1, 2, ... = Number of included instances. The instances of a protection function represent the number of identical protection function blocks
available in the standardized configuration.
() = optional
1) Io selectable by parameter and default value is "Io measured"
2) "Uo measured" is always used
3) Io selectable by parameter and default value is "Io calculated"
3.2 Switch groups
The default application configurations cover the most common application cases,
however, changes can be made according to specific needs through LHMI, WHMI
and PCM600.
Section 3 1MRS757456 D
REF611 standardized configurations
28 REF611
Application Manual
