ABB SACE Emax E1.2 User Manual

ABB | SACE Emax 2
184 | © 2017 ABB | 1SDH001330R0002 - ECN000058721 Rev. A Electronic accessories | 3 - Ekip Measuring modules
Continued from the previous page
The following table shows the configuration parameters of the modules:
Parameter Values Default Description
Voltage
Transf.
Absent, Present Absent
• Absent = Isolation transformer on
the supply side of the inputs of the
module is absent.
• Present = Isolation transformer on
the supply side of the inputs of the
module is present.
Rated voltage
100 V, 115 V, 120 V, 190 V, 208 V,
220 V, 230 V, 240 V, 277 V, 347 V,
380 V, 400 V, 415 V, 440 V, 480 V,
500 V, 550 V, 600 V, 660 V, 690 V
400 V
Displayed with "Voltage Transf." set
as absent: the rated voltage of the
installation.
Primary
voltage
100 V, 115 V, 120 V, 190 V, 208 V,
220 V, 230 V, 240 V, 277 V, 347 V,
380 V, 400 V, 415 V, 440 V, 480 V,
500 V, 550 V, 600 V, 660 V, 690 V,
910 V, 950 V, 1000 V, 1150 V
400 V
Displayed with "Voltage Transf." set
as present: the primary voltage of
the isolation transformer.
Secondary
voltage
100 V, 110 V, 115 V, 120 V, 200 V,
230 V
100 V
Displayed with "Voltage Transf." set
as present: the secondary voltage of
the isolation transformer.
Power flow Bottom->Top, Top->Bottom Low->High
• Bottom->Top = Flow of power
from the low terminals to the high
terminals of the circuit-breaker (load
connected to top).
• Top->Bottom = Flow of power
from the high terminals to the low
terminals the circuit-breaker (load
connected to bottom).
Neutral
connection
Absent, Present Present
• Present = It enables measurement
of the phase voltages.
• Absent = It disables measurement
of the phase voltages (only it
enables measurement of line-to-line
voltages).
The following table shows the path from the display to get information on the modules:
About
Protection Unit
Circuit-breaker
Modules
…
Ekip Measuring
…
Power Controller
The items of information on the modules that can be displayed are the serial number and the version ("Basic"
in the case of Ekip Measuring, "Pro" in the case of Ekip Measuring Pro).
Signallings
A
The following table shows the possible signals, and their meaning:
Pos. Description
A
Power status LED, green; present only on the Ekip Measuring Pro. The possible states are:
• Off: the power supplied by the Ekip Measuring Pro to the trip unit is absent.
• On fixed: the power supplied by the Ekip Measuring Pro to the trip unit is present.
