KNX control elements and application parameters
"Dimmer" control element
Product manual 2CKA00xx73xxxxx
119
10.3 "Dimmer" control element
10.3.1 Name of the control element
Options: <Name>
Naming the dimmer control element, e.g. name of the lamp that is to be dimmed.
The length of the name is limited to 36 characters.
10.3.2 Function of the control element
Options: Not defined (grey)
Light (yellow)
Blind (blue)
Temperature (orange)
Scene (magenta)
Alarm (red)
Feedback (green)
The parameter is used to specify the colour of the function line.
"Light (yellow)" has been made available for functions of this type.
10.3.3 Size of the button
Options: 1 column
2 columns
The parameter is used to specify whether the control element occupies one column (one button
or control frame) or two columns (two buttons or control frames).
10.3.4 Icon type
Options: Standard
User-defined
The parameter is used to set whether a standard icon or a self-selected icon is displayed.
