KNX control elements and application parameters
Control element: "Value slider"
Product manual 2CKA00xx73xxxxx
160
10.12.7 Object type
Options: 1-byte value [0% - 100%]
1-byte value [0 - 255]
1-byte value [-128 - 127]
2-byte value [0 - 65535]
2-byte value [-32768 - +32767]
2-byte floating point
4-byte value [0 - 4294967295]
4-byte value [-2147483648 - 2147483647]
When actuated, the control element can send telegrams via the associated communication
object.
Parameter "Object type" is used to specify the size of the communication object.
– 1-byte value [0% - 100%]: A value is sent as 1-byte value without a sign (percentage value).
– 1-byte value [0 - 255]: A value is sent as 1-byte value without a sign, e.g. actuating value,
angle or brightness value.
– 1-byte value [-128 - 127]: A value is sent as 1-byte value with a sign, e.g. actuating value.
– 2-byte value [0 - 65535]: A value is sent as 2-byte value without a sign, e.g. actuating value
or time interval.
– 2-byte value [-32768 - +32767]: A value is sent as 2-byte value with a sign, e.g. actuating
value or time difference.
– 2-byte floating point: A value is sent as 2-byte floating point value, e.g. a temperature value,
a time duration, a performance or a consumption value.
– 4-byte value [0 - 4294967295]: A value is sent as 4-byte value without a sign, e.g. actuating
value.
– 4-byte value [-2147483648 - 2147483647]: A value is sent as 4-byte value with a sign, e.g.
actuating value or time difference.
The following supplementary parameters are available for all options:
Notice
Different values can be set, depending on the selected option.
Value change:
Options: Setting option depends on the selected object type.
The parameter is used to specify the steps in which a change in values is made.
Minimum object value:
Options: Setting option depends on the selected object type.
The parameter is used to specify the smallest value that is sent via telegrams.
Any value within the limits specified by the object type and its value range can be entered.
