ABB SmartTouch i-bus KNX User Manual

Communication objects
Application "Internal RTC"
Product manual 2CKA00xx73xxxxx
│
254
Name
Object
function
Length Data type Flags
K L S U A
External inside temperature Input 2 bytes
[9.001]
Temperature
(°C)
K - S - A
Outside temperature Input 2 bytes
[9.001]
Temperature
(°C)
K - S - A
Inside temperature Output 2 bytes
[9.001]
Temperature
(°C)
K - S - A
In operation Output 1 bit
[1.001]
Switching
K - - U -
Door communication
Volume of bell sound
Input/
Output
1 byte
[5.001]
Percent
(0 - 100%)
K - S U A
Increase/decrease volume of
bell sound
Input 4 bit
[5.001]
Percent
(0 - 100%)
K - S - A
Voice volume
Input/
Output
1 byte
[5.001]
Percent
(0 - 100%)
K - S U A
Increase/decrease voice
volume
Input 4 bit
[5.001]
Percent
(0 - 100%)
K - S - A
Ringing Output 1 bit
[1.001]
Switching
K - - U -
Start of call Output 1 bit
[1.001]
Switching
K - - U -
End of call Output 1 bit
[1.001]
Switching
K - - U -
Mute incoming calls
Input/
Output
1 bit
[1.001]
Switching
K - S U A
Switch Light Input 1 bit
[1.001]
Switching
K - S U A
Open door Input 1 bit
[1.001]
Switching
K - S U A
Control element 1 Output 1 bit
[1.001]
Switching
K - - U -
Control element 2 Output 1 bit
[1.001]
Switching
K - - U -
Control element 3 Output 1 bit
[1.001]
Switching
K - - U -
Control element 4 Output 1 bit
[1.001]
Switching
K - - U -
Control element 5 Output 1 bit
[1.001]
Switching
K - - U -
Inputs
Binary input Output 1 bit
[1.001]
Switching
K - - U -
Temperature sensor Output 2 bytes
[9.001]
Temperature
(°C)
K - - U -
