Chapter 1 17
Hardware Specifications and Configurations
System Board Major Chips
Item Controller
System core logic ALI M1632M with DRAM/Cache controller
Super I/O controller ALI M1535
Audio controller Cirrus Logic CS4299 or Realtek ALC200 Audio Codec 97
Video controller Trident VGA integrated by north bridge ( 8MB viseo RAM shared from
system memory)
Hard disk drive controller Embedded in M1535
Keyboard controller M38867
RTC BQ3285LF
Processor
Item Specification
CPU type Intel Celeron 700-900 MHz processor with 128K cache
CPU package uBGA2
CPU core voltage 1.6V
CPU I/O voltage 1.5V
BIOS
Item Specification
BIOS vendor Acer BIOS
BIOS Version V3.3
BIOS ROM type Flash ROM
BIOS ROM size 512KB
BIOS package 32 Pin PLCC
Supported protocols ACPI 1.0b, APM 1.2, PC Card 95, SM BIOS 2.3, EPP/IEEE 1284, ECP/
IEEE 1284 1.7 & 1.9, IrDA, PCI 2.1, PnP 1.0a, PS/2 keyboard and mouse,
USB, VESA VGA BIOS, DDC-2B, CD-ROM bootable, Windows keyboard
Microsoft Simple Boot Flag
BIOS password control Set by switch, see SW1 settings
Second Level Cache
Item Specification
Cache controller Built-in CPU
Cache size 128KB
1st level cache control Always Enabled
2nd level cache control Always Enabled
Cache scheme control Fixed-in write back
System Memory
Item Specification
Memory controller ALI M1632
Onboard memory size 0MB
DIMM socket number 2 Sockets
Supports memory size per socket 32/64/128/256 MB
Supports maximum memory size 512 MB ( 256MB x 2 )
