Chapter 3 55
Disassembling the LCD
Removing the Hinge Cap
1.
To remove the hinge caps, push the hinge caps outward then slide the hinge caps out from the main unit.
Removing the Middle Cover
1.
See “Removing the Hinge Cap” on page 55
2.
To remove the middle cover, push the middle cover rightward and lift the middle cover away.
Removing the Launch Board
1.
See “Removing the Hinge Cap” on page 55
2.
See “Removing the Middle Cover” on page 55
3.
Disconnect the launch board cable from the launch board.
