Chapter 5 91
Bottom View
CN19 Modem Card Cable Connector CN23 Audio Connector
CN20 Power Push Switch DM1 DIMM 1 Socket(Reverse)
CN21 Battery Connector DM2 DIMM 2 Socket
CN22 Modem Connector
CN19
CN20
CN23
CN22
DM1
DM2
CN21
