Chapter 3 67
Removing the Upper Case
1.
See “Removing the Hinge Cap” on page 55
2.
See “Removing the Middle Cover” on page 55
3.
See “Removing the Keyboard” on page 56
4.
See “Removing the Cable Cover” on page 56
5.
See “Removing the 12.1” TFT LCD Module” on page 57
6.
See “Removing the CPU Heatsink” on page 64
7.
To remove the upper case, first remove eight screws from the base of the unit as shown.
8.
Pull the upper case from the unit gently.
