156 Agilent U1251B/U1252B User’s and Service Guide
7 Specifications
Specification Assumptions
• The DC specifications are defined for measurements
which are taken after at least 1 minute of warm- up time.
• The AC and AC+DC specifications are defined for
measurements of sine wave and are taken after at least 1
minute of warm- up time.
• The accuracy of the multimeter may be affected when
making measurements in an environment where
electromagnetic interferences or significant electrostatic
charges are present.
Electrical Specifications
DC Specifications
Tab l e 7-1 DC Accuracy ± (% of reading + Number of Least Significant Digit)
Function Range Resolution
Test Current/
Burden Voltage
Accuracy
U1251B U1252B
Voltage
[1]
50.000 mV 0.001 mV - 0.05 + 50
[2]
0.05 + 50
[2]
500.00 mV 0.01 mV -
0.03 + 5
0.025 + 5
1000.0 mV 0.1 mV -
5.0000 V 0.0001 V -
50.000 V 0.001 V -
500.00 V 0.01 V - 0.03 + 5
1000.0 V 0.1 V -
Notes for DC voltage specifications:
1 Input impedance: Refer to Ta b l e 7 - 1 9 .
2 The accuracy could be 0.05 % + 10 for U1251B and 0.05 % + 5 for U1252B. Always use the Null function to zero out the
thermal effect before measuring the signal.
