Specifications 7
Agilent U1251B/U1252B User’s and Service Guide 159
AC Specifications
AC specifications for U1251B
Tab l e 7-2 U1251B accuracy specifications ± (% of reading + number of LSD) for true RMS AC voltage
Function Range Resolution
Frequency
30 Hz to 45 Hz 45 Hz to 1 kHz 1 kHz to 5 kHz 5 kHz to 30 kHz
Voltage
[1][2]
50.000 mV 0.001 mV 1 + 60 0.6 + 40 1.0 + 40 1.6 + 60
500.00 mV 0.01 mV 1 + 60 0.6 + 25 1.0 + 40 1.6 + 60
1000.0 mV 0.1 mV 1 + 60 0.6 + 25 1.0 + 25 3.5 + 120
5.0000 V 0.0001 V 1 + 60 0.6 + 25 1.0 + 25 3.5 + 120
50.000 V 0.001 V 1 + 60 0.6 + 25 1.0 + 25 3.5 + 120
500.00 V 0.01 V 1 + 60 0.6 + 25 1.0 + 25 -
1000.0 V 0.1 V 1 + 60 0.6 + 40 1.0 + 40 -
Notes for U1251B AC voltage specifications:
1 Input impedance: Refer to Ta b l e 7 - 1 9 .
2 AC mV/V and AC µA/mA/A specifications are true RMS AC coupled, valid from 5% to 100% of range. The crest factor
may be up to 3 at full scale, up to 5 at half-scale, except for 1000 mV and 1000 V ranges, where the crest factor is 1.5 at full
scale and 3 at half scale.
Tab l e 7-3 U1251B accuracy specifications ± (% of reading + number of LSD) for true RMS AC current
Function Range Resolution
Frequency
30 Hz to 45 Hz 45 Hz to 2 kHz 2 kHz to 20 kHz
Current
[1]
500.00 µA
[2]
0.01 µA 1.5 + 50 0.8 + 20 3 + 80
5000.0 µA 0.1 µA 1.5 + 40 0.8 + 20 3 + 60
50.000 mA 0.001 mA 1.5 + 40 0.8 + 20 3 + 60
440.00 mA 0.01 mA 1.5 + 40 0.8 + 20 3 + 60
5.0000 A 0.0001 A 2 + 40
[4]
0.8 + 20 3 + 60
< 3 A/5 kHz
10.000 A
[3]
0.001 A 2 + 40
[4]
0.8 + 20
Notes for U1251B AC current specifications:
1 AC mV/V and AC µA/mA/A specifications are true RMS AC coupled, valid from 5% to 100% of range. The crest factor
may be up to 3 at full scale, up to 5 at half-scale, except for 1000 mV and 1000 V ranges, where the crest factor is 1.5 at full
scale and 3 at half scale.
2 Input current > 35 µArms.
3 Current can be measured from 2.5 A up to 10 A continuously. Add 0.5% to the specified accuracy if the signal measured is
in the range of 10 A to 20 A and for a period of up to 30 seconds. After measuring current > 10 A, leave the meter to cool
down for a period that is twice the measuring time used before application of low current measurement.
4 Input current < 3 Arms.
