50 Agilent U1251B/U1252B User’s and Service Guide
3 Features and Functions
Dynamic Recording
The Dynamic Recording mode can be used to detect
intermittent turn- on or turn- off voltage, current surges or to
verify measurement performance without you being present
during the process. While the readings are being recorded,
you are free to perform other tasks.
The average reading is useful for smoothing out unstable
inputs, estimating the percentage of time a circuit is
operating and verifying circuit performance. The elapsed
time is shown on the secondary display. The maximum time
is 99999 seconds. When this maximum time is exceeded
“OL” is shown on the display.
1 Press for more than 1 second to enter Dynamic
Recording mode. The meter is now in continuous mode or
non- data hold (non- trigger) mode. “MAXMINAVG” and
present value of measurement are displayed. The
multimeter will beep when a new maximum or minimum
value is recorded.
2 Press to cycle through maximum, minimum,
average, and present readings. The MAX, MIN, AVG, and
MAXMINAVG indicators light up, corresponding to the
displayed readings.
3 Press or for more than 1 second to exit
Dynamic Recording mode.
• Press to restart the dynamic recording.
• The average value is the true average of all the measured values taken
in the Dynamic Recording mode. If an overload is recorded, the
averaging function will stop and the average value becomes
"OL"(overload). is disabled in Dynamic Recording mode.
