Agilent Technologies U1252B User Manual

Getting Started Tutorial 1
Agilent U1251B/U1252B User’s and Service Guide 5
To adjust the meter to a hanging position follow the steps
shown in Figure 1- 3 below.
Figure 1-3 Tilt-stand at hanging position
3. Flip the tilt-stand over until
this side of
4. Re-attach the tilt-stand to an
upright position
1. Extend the tilt-stand until its
maximum reach
2. Detach the tilt-stand
the stand is facing
the multimeter as
opposed to facing you

Agilent Technologies U1252B Specifications

General

Max Voltage Measurement	1000 V
Max Current Measurement	10 A
Resistance Measurement	Yes
Capacitance Measurement	Yes
Frequency Measurement	Yes
Temperature Measurement	Yes
Data Logging	Yes
Operating Temperature	0 °C to 50 °C
Safety Category	CAT III 1000 V, CAT IV 600 V
Diode Test	Yes
Continuity Test	Yes
DC Voltage Range	100.00 mV to 1000.0 V
AC Voltage Accuracy	0.5%
DC Current Range	100 µA to 10 A
AC Current Range	100 µA to 10 A
Resistance Range	100 Ω to 100 MΩ
Temperature Range	-40°C to 1000°C
Connectivity	USB
Weight	Approx. 500 g
