3 Measurement Tutorial

60 U3402A User’s and Service Guide

Measure True RMS AC+DC

The multimeter can measure the true RMS value of the AC voltage and AC

current.

1 Press and , or and simultaneously. The

multimeter will measure the DC and AC signals alternatively, calculate and

display the AC+DC (RMS) value using the equation below:

AC+DC (RMS) = DC

+ AC

NOTE

When AC+DC voltage measurement is selected, the DCV input impedance is paralleled

with the AC coupled 1.1 M

AC divider.
