Frequently Used Parameters
Footnote definitions are found on page 48.
No.
(1)
Name
Description
(2)
Values
(3)
Linkable Read-Write Data Type
1 Motor NP Volts
Set to the motor nameplate rated volts.
Units:
Default:
Min/Max:
Volt
Calculated
75/705
RW 16-bit
Integer
2 Motor NP FLA
Set to the motor nameplate rated full load amps. Range limited by three-second inverter
rating.
Units:
Default:
Min/Max:
Amps
Calculated
Calculated/Calculated
RW Real
3 Motor NP Hertz
Set to the motor nameplate rated frequency.
Units:
Default:
Min/Max:
Hz
Calculated
2.0000/500.0000
RW Real
4 Motor NP RPM
Set to the motor nameplate rated RPM.
Units:
Default:
Min/Max:
RPM
Calculated
1/30000
RW 16-bit
Integer
5 Motor NP Power
Set to the motor nameplate rated power.
Units:
Default:
Min/Max:
Hp
Calculated
0.2500/3500.0000
RW Real
6 Mtr NP Pwr Units
The power units shown on the motor nameplate.
Default:
Options:
0
0
1
Hp
Hp
W
10 Speed Ref 1
Sets the speed reference that the drive should use when selected by Parameter 16
[Speed Ref Sel]. A value of 1.0 represents base speed of the motor.
Default:
Min/Max:
0.0000
-/+2200000000.0000
✓ RW Real
16 Speed Ref Sel
Selects the source of the speed reference to the drive.
Default:
Options:
1
0
1
2
3
“Spd Ref DPI”
“Zero Speed” 4 “Spd Ref 4”
“Spd Ref 1 5 “Spd Ref 5”
“Spd Ref 2” 6 “Spd Ref DPI”
“Spd Ref 3
30 Rev Speed Limit
Sets a limit on the speed reference in the negative direction. This value can be entered as
a negative value or zero.
Units:
Default:
Min/Max:
Comm Scale:
RPM
-2205.0000
-14112.0000/0.0000
Parameter 4 [Motor NP RPM] = 1.0
RW Real
31 Fwd Speed Limit
Sets a limit on the speed reference in the positive direction. This value can be entered as
a positive value or zero.
Units:
Default:
Min/Max:
Comm Scale:
RPM
2205.0000
0.0000/14112.0000
Parameter 4 [Motor NP RPM] = 1.0
RW Real
32 Accel Time
Sets the rate of acceleration for all speed increases, with time in seconds to base speed.
Accel Rate = Parameter 4 [Motor NP RPM] / Parameter 32 [Accel Time]
Units:
Default:
Min/Max:
Sec
10.0000
0.0100/6553.5000
✓ RW Real
33 Decel Time
Sets the rate of deceleration for all speed decreases, with time in seconds to base speed.
Decel Rate = Parameter 4 [Motor NP RPM] / Parameter 33 [Decel Time]
Units:
Default:
Min/Max:
Sec
10.0000
0.0100/6553.5000
✓ RW Real
34 S Curve Time
Sets the S time (Round In and Round Out ) in seconds. Half of the time specified is
added to the beginning and half to the end of the applied ramp. The S time is
independent of speed and results in a trapezoidal torque profile.
Units:
Default:
Min/Max:
Sec
0.5000
0.0000/4.0000
✓ RW Real
90 Spd Reg BW
Sets the bandwidth of the speed regulator in rad/sec. Bandwidth is also referred to as the
crossover frequency. Small signal time response is approximately 1/BW and is the time to
reach 63% of set point. A change to this parameter will cause an automatic update of
Parameters 81 [Spd Reg P Gain] and 82 [Spd Reg I Gain]. To disable the automatic gain
calculation, set this parameter to a value of zero.
Adjustments to Parameters 474 [Freq Reg We BW] and 475 Freq Reg Wr BW] may be
necessary when using sensorless feedback.
Units:
Default:
Min/Max:
R/S
10.0000
0.0000/500.0000
✓ RW Real
153 Control Options
Set bits to configure the options for operating the drive.
Options
Reserved Reserved Reserved Reserved Reserved Trq Tr im En Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Aux Pwr Sply Auto Tach Sw Reserved Reserved OL ClsLpDsbl Jog -NoInteg Iq Delay Motor Dir 2W CoastStop 3WireControl Stop Cndt Tq Stop in Torq Jog - NoRamp Jog in Torq 2WCurrLimStp Sreg LPF 1 SRef Filt En Bipolar SRef
Default0000000000000000000000010000000 1
Bit 313029282726252423222120191817161514131211109 8 7 6 5 4 3 2 1 0
0 = False
1 = True
