Allen-Bradley PowerFlex 700S Quick Start

6 PowerFlex® 700S Drives - Phase I Control (Frame Sizes 9 & 10)
CE Conformity
Conformity with the Low Voltage (LV) Directive and Electromagnetic
Compatibility (EMC) Directive has been demonstrated using harmonized European
Norm (EN) standards published in the Official Journal of the European
Communities. PowerFlex Drives comply with the EN standards listed below when
installed according to the User and Reference Manual.
CE Declarations of Conformity are available online at:
http://www.ab.com/certification/ce/docs.
Low Voltage Directive (73/23/EEC)
• EN50178 Electronic equipment for use in power installations.
EMC Directive (89/336/EEC)
• EN61800-3 Adjustable speed electrical power drive systems Part 3: EMC
product standard including specific test methods.
General Notes
• The motor cable should be kept as short as possible in order to avoid
electromagnetic emission as well as capacitive currents.
• Use of line filters in ungrounded systems is not recommended.
• PowerFlex drives may cause radio frequency interference if used in a residential
or domestic environment. The user is required to take measures to prevent
interference, in addition to the essential requirements for CE compliance listed
below, if necessary.
• Conformity of the drive with CE EMC requirements does not guarantee an entire
machine or installation complies with CE EMC requirements. Many factors can
influence total machine/installation compliance.
• PowerFlex drives can generate conducted low frequency disturbances (harmonic
emissions) on the AC supply system. More information regarding harmonic
emissions can be found in the Reference Manual - PowerFlex 700S Drives with
Phase I Control, PFLEX-RM002.
Essential Requirements for CE Compliance
Conditions 1-6 listed below must be satisfied for PowerFlex drives to meet the
requirements of EN61800-3.
1. Standard PowerFlex High Power CE compatible Drive. For Frame 10, the drive
must also be installed in a suitable Rittal TS 8 (or equivalent) enclosure.
2. Review important precautions/attention statements throughout this manual
before installing the drive.
3. Grounding as described on page 25
.
4. Output power, control (I/O) and signal wiring must be braided, shielded cable
with a coverage of 75% or better, metal conduit or equivalent attenuation.
5. All shielded cables should terminate with the proper shielded connector.
6. Conditions in Table A
.
