Decel Time 2-45
Decel Time [Decel Time 1, 2]
Sets the rate at which the drive ramps down its output frequency after a Stop
command or during a decrease in command frequency (speed change). The
rate established is the result of the programmed Decel Time and the
Minimum and Maximum Frequency, as follows:
Two Decel times exist to allow the user to change rates “on the fly” via PLC
command or Digital Input. The selection is made using the 1st/2nd Decel
inputs shown below or a similar pattern of decel time select bits in the Logic
Control word used via PLC communications.
Times are adjustable in 0.1 second increments from 0.0 seconds to 3600.0
seconds.
In its factory default condition, when no Decel select inputs are closed and
no time bits are “1,” the default deceleration time is [Decel Time 1] and the
rate is determined as above.
Maximum Frequency – Minimum Frequency
Decel Time
= Decel Rate
