Programming
52
4" Color Touch Panels with Audio
Programming Numbers
The following information provides the programming numbers for colors, fonts, and borders.
Colors can be used to set the colors on buttons, sliders, gauges, and pages. The lowest color number
represents the lightest color-specific display; the highest number represents the darkest display. For
example, 0 represents light red, and 5 is dark red.
System Send_Commands (Cont.)
WAKE
Deactivates
screen-saver
mode and resets
the sleep timer.
Syntax:
"’WAKE’"
Example:
SEND_COMMAND TP,"’WAKE’"
Deactivates the touch panel screen-saver mode and resets the sleep timer.
XMRT
Sets the new net-
work communica-
tion retry value for
the panel and
SoftROM.
Syntax:
"’XMRT <number>’"
Variable:
number = 1 - 15 ASCII characters
Example:
SEND_COMMAND TP,"’XMRT 9’"
Sets the XMODEM wait for character retries to 9.
XMTO
Sets the new net-
work communica-
tion delay for the
panel and Soft-
ROM.
Syntax:
"’XMTO <number>’"
Variable:
number = 4 - 30 ASCII characters
Example:
SEND_COMMAND TP,"’XMTO 5’"
Sets the new XMODEM character delay time to 5 seconds.
ZAP!
Clears all mem-
ory; erases but-
tons, pages,
drawings, and
symbols.
Syntax:
"’ZAP!’"
Example:
SEND_COMMAND TP,"’ZAP!’"
Clears all memory and erases all buttons, pages, drawings, and symbols.
See Warning information on page 52 for more information.
Only use the ZAP! command to erase the saved data in the touch panel; data cannot be
recovered after it is erased.
Colors and Programming Numbers
Color No. Color No.
Red 0 - 5 Purple 54 - 59
Orange 6 - 11 Magenta 60 - 65
Yellow 12 - 17 Pink 66 - 71
Lime 18 - 23 White 72 - 77
Green 24 - 29 Grey 78 - 83
Aqua 30 - 35 More Grey 84 - 86
Cyan 36 - 41 Black 87
Royal 42 - 47 Transparent 255
